GIGABYTE GA-MA74GM-S2 motherboard AMD

GIGABYTE GA-MA74GM-S2 motherboard AMD

740G Socket AM2 ATX

Model GA-MA74GM-S2EAN 818313005649

47 specifications
  • Processor manufacturerAMD
  • Number of memory slots2
  • RAID levels0, 1
  • USB 2.0 connectors4
  • LAN controllerRealtek RTL8111C
  • Motherboard form factorATX
See all specifications

Overview

Processor manufacturer
AMD
Number of memory slots
2
RAID levels
0, 1
USB 2.0 connectors
4
LAN controller
Realtek RTL8111C
Motherboard form factor
ATX
Brand
GIGABYTE
Category
Motherboard
Model
GA-MA74GM-S2
Part number
GA-MA74GM-S2
EAN / UPC
818313005649, 4719331815219, 5052179242380
Also known as
GIGABYTE GA-MA74GM-S2 motherboard AMD 740G Socket AM2 ATX

Specifications

47 specifications in 11 groups

Processor

Processor manufacturerAMD
Processor socketSocket AM2

Memory

Number of memory slots2
Memory voltage1.8 V
Maximum internal memory8 GB

Storage controllers

RAID levels0, 1

Internal I/O

USB 2.0 connectors4
Number of SATA connectors6
Number of Parallel ATA connectors1
S/PDIF out connectorYes
Front panel audio connectorYes
CD/AUX audio inYes
ATX Power connector (24-pin)Yes
Number of EATX power connectors1
Power fan connectorYes
CPU fan connectorYes
Chassis intrusion connectorYes

Rear panel I/O ports

USB 2.0 ports quantity4
Ethernet LAN (RJ-45) ports1
eSATA ports quantity0
PS/2 ports quantity2
Firewire (IEEE 1394) ports0
VGA (D-Sub) ports quantity1
HDMI ports quantity0
DVI-D ports quantity1
Headphone outputs3
Microphone inYes
S/PDIF out portYes
Parallel ports quantity1

Network

LAN controllerRealtek RTL8111C
Networking features10/100/1000 Mbit

Features

Motherboard form factorATX
Motherboard chipsetAMD 740G
Audio chipRealtek ALC888
Audio output channels7.1 channels
Power source typeATX
Compatible operating systemsWindows Vista/XP/ME/9X

Expansion slots

PCI Express x1 slots1
PCI Express x16 slots1
PCI slots2

Weight & dimensions

Width244 mm
Depth234 mm

Packaging content

Drivers includedYes
Bundled softwareNorton Internet Security

Other features

Controller interface typeiTE IT8718
Floppy disk drive connectorYes
Special features@BIOS Download Center Q-Flash EasyTune (Note 5) Xpress Install Xpress Recovery2 Virtual Dual BIOS
