GIGABYTE GA-EG31MF-S2 motherboard LGA 775 (Socket T) ATX
Model GA-EG31MF-S2EAN 4719331808068
35 specifications
- Processor manufacturerIntel
- Number of memory slots4
- Motherboard form factorATX
- PCI Express x1 slots1
- Width244 mm
Overview
- Processor manufacturer
- Intel
- Number of memory slots
- 4
- Motherboard form factor
- ATX
- PCI Express x1 slots
- 1
- Width
- 244 mm
- Brand
- GIGABYTE
- Category
- Motherboard
- Model
- GA-EG31MF-S2
- Part number
- GA-EG31MF-S2
- EAN / UPC
- 4719331808068
- Also known as
- GIGABYTE GA-EG31MF-S2 motherboard LGA 775 (Socket T) ATX
Specifications
35 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | LGA 775 (Socket T) |
| Compatible processor series | Intel® Celeron®, Intel® Pentium® 4, Intel® Pentium® D |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 4 |
| Memory voltage | 1.8 V |
| Maximum internal memory | 4 GB |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 4 |
| Number of SATA connectors | 4 |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 1 |
| Chassis intrusion connector | Yes |
| Number of COM connectors | 2 |
| Number of IEEE1394 connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| eSATA ports quantity | 0 |
| PS/2 ports quantity | 2 |
| Firewire (IEEE 1394) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 0 |
| DVI-D ports quantity | 0 |
| Microphone in | Yes |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | ATX |
| Audio output channels | 5.1 channels |
| Power source type | ATX |
| Compatible operating systems | Microsoft Windows Vista/XP/2000 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 slots | 1 |
| PCI Express x16 slots | 1 |
| PCI slots | 2 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 244 mm |
| Depth | 220 mm |
Other features
| Specification | Value |
|---|---|
| Floppy disk drive connector | Yes |
