GA-8VM800M-478 motherboard VIA K8M800 Socket 754 ATX
Model GA-8VM800M-478
10 specifications
- Processor manufacturerAMD
- Maximum internal memory2 GB
- Motherboard form factorATX
Overview
- Processor manufacturer
- AMD
- Maximum internal memory
- 2 GB
- Motherboard form factor
- ATX
- Brand
- GIGABYTE
- Category
- Motherboard
- Model
- GA-8VM800M-478
- Part number
- GA-8VM800M-478
- Also known as
- GIGABYTE GA-8VM800M-478 motherboard VIA K8M800 Socket 754 ATX
Specifications
10 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor socket | Socket 754 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory | 2 GB |
Network
| Specification | Value |
|---|---|
| Networking features | Ethernet 10/100Mb LAN Network Connection |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | ATX |
| Motherboard chipset | VIA K8M800 |
| Power source type | ATX |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 1 x AGP slot (8x/4x-AGP 3.0 compliant), supports 1.5v display card only. 3 x PCI slots (PCI 2.2 compliant) |
Other features
| Specification | Value |
|---|---|
| Audio output | Realtek ALC655 Audio AC'97 CODEC |
| I/O ports | Internal I/O Connectors 2 x Serial ATA connector 2 x UDMA ATA 133/100/66 Bus Master IDE connectors 1 x FDD connector 2 x USB 2.0/1.1 connectors (supports 4 ports) S/P DIF input/output pin header 2 x cooling fan pin headers CD/AUX in 1 x Game/Midi connector Rear Panel I/O PS/2 Keyboard / Mouse 4 x US |
