GIGABYTE G1.Sniper 5

GIGABYTE G1.Sniper 5

Model G1.Sniper 5Part no. G1.SNIPER 5EAN 8183130169594

80 specifications
  • Processor manufacturerIntel
  • Supported memory typesDDR3-SDRAM
  • Supported storage drive interfacesSATA, SATA II, SATA III
  • On-board graphics cardYes
  • USB 2.0 connectors2
  • Component forPC
See all specifications

Overview

Processor manufacturer
Intel
Supported memory types
DDR3-SDRAM
Supported storage drive interfaces
SATA, SATA II, SATA III
On-board graphics card
Yes
USB 2.0 connectors
2
Component for
PC
Brand
GIGABYTE
Category
Motherboard
Model
G1.Sniper 5
Part numbers
G1.SNIPER 5, G1.Sniper 5-R1, G1.Sniper 5-R1.x
EAN / UPC
8183130169594, 818313016959, 4719331815295
Also known as
GIGABYTE G1.Sniper 5 Intel® Z87 LGA 1150 (Socket H3) Extended ATX

Specifications

80 specifications in 14 groups

Processor

Processor manufacturerIntel
Processor socketLGA 1150 (Socket H3)
Compatible processor seriesIntel® Celeron®, Intel® Pentium®
Maximum number of SMP processors1
Supported processor socketsLGA 1150 (Socket H3)

Memory

Supported memory typesDDR3-SDRAM
Number of memory slots4
Memory slots typeDIMM
Memory channelsDual-channel
Memory voltage1.5 V
ECC сompatibilityNon-ECC
Supported memory clock speeds1333,1600,3000 MHz
Maximum internal memory32 GB
Unbuffered memoryYes

Storage controllers

Supported storage drive interfacesSATA, SATA II, SATA III
RAID levels0, 1, 5, 10

Graphics

Parallel processing technology support2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, 3-Way SLI, 4-Way CrossFireX, 4-Way SLI
On-board graphics cardYes
Graphics card familyIntel
Graphics cardHD Graphics
Maximum resolution4096 x 2160 pixels
HDCPYes
Discrete graphics supportYes

Internal I/O

USB 2.0 connectors2
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
Number of SATA III connectors10
Number of SATA II connectors0
Number of Parallel ATA connectors0
Front panel audio connectorYes
ATX Power connector (24-pin)Yes
CPU fan connectorYes
Number of chassis fan connectors8
Chassis intrusion connectorYes
Peripheral (Molex) power connectors (4-pin)1
EPS power connector (8-pin)Yes

Rear panel I/O ports

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
Ethernet LAN (RJ-45) ports2
eSATA ports quantity0
PS/2 ports quantity1
Firewire (IEEE 1394) ports0
VGA (D-Sub) ports quantity0
HDMI ports quantity2
HDMI version1.4a
DVI-D ports quantity0
DisplayPorts quantity1
Headphone outputs5
Microphone inYes
S/PDIF out portYes
Digital audio optical out1

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g
BluetoothYes
Bluetooth version4.0

Features

Component forPC
Motherboard form factorExtended ATX
Motherboard chipset familyIntel
Motherboard chipsetIntel® Z87
Audio output channels5.1 channels
PC health monitoringCPU, Fan, Temperature
Cooling typeActive
Power source typeATX
Windows operating systems supportedYes

Expansion slots

PCI Express x1 slots3
PCI Express x16 slots4
PCI Express configurations2x8, 2x16
PCI Express slots version2.0, 3.0

BIOS

BIOS typeEFI AMI
BIOS memory size16 Mbit
ACPI version2.0a
Clear CMOS jumperYes
Clear CMOS buttonYes

Processor special features

Intel® High Definition Audio (Intel® HD Audio)Yes
Processor with Intel Graphics Technology requiredYes

Weight & dimensions

Width305 mm
Depth264 mm

Packaging content

Cables includedSATA

Other features

Quick installation guideYes
