Fujitsu GA-8I848PM-FS Motherboard
Model GA-8I848PM-FS MotherboardPart no. FSP:140000514
31 specifications
- Processor manufacturerIntel
- Number of memory slots2
- Number of SATA connectors1
- USB 2.0 ports quantity8
- Networking featuresEthernet, Fast Ethernet
- Motherboard form factormicro ATX
Overview
- Processor manufacturer
- Intel
- Number of memory slots
- 2
- Number of SATA connectors
- 1
- USB 2.0 ports quantity
- 8
- Networking features
- Ethernet, Fast Ethernet
- Motherboard form factor
- micro ATX
- Brand
- Fujitsu
- Category
- Motherboard
- Model
- GA-8I848PM-FS Motherboard
- Part number
- FSP:140000514
- Also known as
- Fujitsu GA-8I848PM-FS Motherboard Socket 478 micro ATX
Specifications
31 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | Socket 478 |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 2 |
| Maximum internal memory | 2 GB |
Internal I/O
| Specification | Value |
|---|---|
| Number of SATA connectors | 1 |
| Front panel audio connector | Yes |
| CD/AUX audio in | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
| Chassis intrusion connector | Yes |
| Number of IEEE1394 connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 8 |
| Ethernet LAN (RJ-45) ports | 1 |
| eSATA ports quantity | 0 |
| PS/2 ports quantity | 2 |
| Firewire (IEEE 1394) ports | 1 |
| VGA (D-Sub) ports quantity | 0 |
| HDMI ports quantity | 0 |
| DVI-D ports quantity | 0 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| S/PDIF out port | Yes |
| Parallel ports quantity | 1 |
| Serial ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking features | Ethernet, Fast Ethernet |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | micro ATX |
| Audio chip | Realtek ALC655 |
| Power source type | ATX |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 244 mm |
| Depth | 244 mm |
Other features
| Specification | Value |
|---|---|
| Floppy disk drive connector | Yes |
