ASUS P8C WS

ASUS P8C WS

Model P8C WSPart no. 90-MSVE30-G0EAY0YZEAN 610839186228

68 specifications
  • Processor manufacturerIntel
  • Supported memory typesDDR3-SDRAM
  • Supported storage drive interfacesSATA II, SATA III
  • Parallel processing technology supportQuad-GPU CrossFireX
  • USB 2.0 connectors1
  • USB 2.0 ports quantity6
See all specifications

Overview

Processor manufacturer
Intel
Supported memory types
DDR3-SDRAM
Supported storage drive interfaces
SATA II, SATA III
Parallel processing technology support
Quad-GPU CrossFireX
USB 2.0 connectors
1
USB 2.0 ports quantity
6
Brand
ASUS
Category
Motherboard
Model
P8C WS
Part number
90-MSVE30-G0EAY0YZ
EAN / UPC
610839186228, 191120007373, 191120098579, 3609740149207 +1 more
Also known as
ASUS P8C WS Intel® C216 LGA 1155 (Socket H2) ATX

Specifications

68 specifications in 13 groups

Processor

Processor manufacturerIntel
Processor socketLGA 1155 (Socket H2)
Compatible processor seriesIntel® Celeron®, Intel® Pentium®
Maximum number of SMP processors1

Memory

Supported memory typesDDR3-SDRAM
Number of memory slots4
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilityECC & Non-ECC
Supported memory clock speeds1333,1600 MHz
Unbuffered memoryYes

Storage controllers

Supported storage drive interfacesSATA II, SATA III
RAID levels0, 1, 5, 10

Graphics

Parallel processing technology supportQuad-GPU CrossFireX
On-board graphics cardYes
Graphics card familyIntel
Discrete graphics supportYes

Internal I/O

USB 2.0 connectors1
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
Number of SATA III connectors2
Number of SATA II connectors4
S/PDIF out connectorYes
Front panel audio connectorYes
ATX Power connector (24-pin)Yes
Number of EATX power connectors1
Power fan connectorYes
CPU fan connectorYes
Number of chassis fan connectors3
Chassis intrusion connectorYes
EPS power connector (8-pin)Yes
Number of COM connectors1
Number of IEEE1394 connectors1
TPM connectorYes

Rear panel I/O ports

USB 2.0 ports quantity6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LAN (RJ-45) ports2
PS/2 ports quantity1
Firewire (IEEE 1394) ports1
DVI-I ports quantity1
Microphone inYes
Digital audio optical out1

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
LAN controllerIntel® 82574L
Networking features2 x Gigabit LAN

Features

Component forPC
Motherboard form factorATX
Motherboard chipset familyIntel
Motherboard chipsetIntel® C216
Audio chipRealtek ALC892
Audio output channels7.1 channels
Cooling typePassive
Power source typeATX
Compatible operating systemsWindows Server 2008 R2 Enterprise Windows Server 2008 Enterprise 32/64-bit Windows Server 2003 R2 Enterprise 32/64-bit Windows 7 32/64-bit Windows XP 32/64-bit

Expansion slots

PCI Express x1 slots1
PCI Express x16 slots4
PCI Express configurations1x16, 2x4, 2x8
PCI Express slots version2.0, 3.0
PCI slots1

BIOS

BIOS typeAMI
BIOS memory size64 Mbit
ACPI version2.0a

Weight & dimensions

Width305 mm
Depth245 mm

Packaging content

Drivers includedYes

Other features

Controller interface typeIntel C216
PCI Express slots quantity5
Quick installation guideYes
