ASUS P5N-T Deluxe
Model P5N-T DeluxePart no. P5N-TDELUXEEAN 5051749352054
39 specifications
- Processor manufacturerIntel
- Number of memory slots4
- RAID levels0, 1, 0+1, 5
- USB 2.0 connectors3
- LAN controllerMarvell 88E1116
- Motherboard form factorATX
Overview
- Processor manufacturer
- Intel
- Number of memory slots
- 4
- RAID levels
- 0, 1, 0+1, 5
- USB 2.0 connectors
- 3
- LAN controller
- Marvell 88E1116
- Motherboard form factor
- ATX
- Brand
- ASUS
- Category
- Motherboard
- Model
- P5N-T Deluxe
- Part numbers
- P5N-TDELUXE, 90-MBB880-G0EAY00Z, 90-MBB880-G0AAY00Z
- EAN / UPC
- 5051749352054, 610839158263, 4719543158265
- Also known as
- ASUS P5N-T Deluxe LGA 775 (Socket T) ATX
Specifications
39 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | LGA 775 (Socket T) |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 4 |
| ECC сompatibility | Non-ECC |
| Maximum internal memory | 8 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1, 0+1, 5 |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 3 |
| Number of SATA connectors | 6 |
| Number of Parallel ATA connectors | 1 |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| CD/AUX audio in | Yes |
| ATX Power connector (24-pin) | Yes |
| Power fan connector | Yes |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 2 |
| Chassis intrusion connector | Yes |
| Number of COM connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| eSATA ports quantity | 1 |
| PS/2 ports quantity | 2 |
| Firewire (IEEE 1394) ports | 1 |
| S/PDIF out port | Yes |
Network
| Specification | Value |
|---|---|
| LAN controller | Marvell 88E1116 |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | ATX |
| Audio chip | ADI AD1988B |
| Audio output channels | 7.1 channels |
| Power source type | ATX |
| Compatible operating systems | Windows 98/2000/XP/Vista 32/64 |
| Overclocking features | Precision Tweaker 2 |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 3 x PCIe x16 2 x PCIe x1 1 x PCI |
BIOS
| Specification | Value |
|---|---|
| BIOS type | Award |
| BIOS memory size | 64 Mbit |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | ASUS PC Probe II ASUS AI Image Editing |
Other features
| Specification | Value |
|---|---|
| Floppy disk drive connector | Yes |
| Special features | ASUS MyLogo 3 |
| Manageability features | WOL PME,WOR PME, PXE |
| RAID controller type | SATA |
