ASUS P5B-VM motherboard LGA 775 (Socket T) micro ATX
Model P5B-VMEAN 610839141180
48 specifications
- Processor socketLGA 775 (Socket T)
- Number of memory slots4
- RAID levels0, 1, JBOD
- Parallel processing technology supportNot supported
- USB 2.0 connectors3
- Networking featuresGigabit Ethernet
Overview
- Processor socket
- LGA 775 (Socket T)
- Number of memory slots
- 4
- RAID levels
- 0, 1, JBOD
- Parallel processing technology support
- Not supported
- USB 2.0 connectors
- 3
- Networking features
- Gigabit Ethernet
- Brand
- ASUS
- Category
- Motherboard
- Model
- P5B-VM
- Part numbers
- P5B-VM, 90-MBB4R5-G0UAYVZ, 90-MBB4R5-G0EAYGZ
- EAN / UPC
- 610839141180, 4719543141182
- Also known as
- ASUS P5B-VM motherboard LGA 775 (Socket T) micro ATX
Specifications
48 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor socket | LGA 775 (Socket T) |
| Maximum number of SMP processors | 1 |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 4 |
| Maximum internal memory | 8 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1, JBOD |
Graphics
| Specification | Value |
|---|---|
| Parallel processing technology support | Not supported |
| On-board graphics card | Yes |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 3 |
| Number of SATA connectors | 5 |
| Number of Parallel ATA connectors | 1 |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| CD/AUX audio in | Yes |
| ATX Power connector (24-pin) | Yes |
| Power fan connector | Yes |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 1 |
| Chassis intrusion connector | Yes |
| Number of COM connectors | 1 |
| Number of IEEE1394 connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| eSATA ports quantity | 1 |
| PS/2 ports quantity | 2 |
| Firewire (IEEE 1394) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 0 |
| DVI-D ports quantity | 0 |
| Parallel ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking features | Gigabit Ethernet |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | micro ATX |
| Audio chip | ADI AD1988 |
| Audio output channels | 7.1 channels |
| Power source type | ATX |
| Compatible operating systems | Windows |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 1x PCI-E x16 1x PCI-E x4 2x PCI 2.2 |
BIOS
| Specification | Value |
|---|---|
| BIOS memory size | 64 Mbit |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 245 mm |
| Depth | 245 mm |
Packaging content
| Specification | Value |
|---|---|
| Drivers included | Yes |
| Bundled software | ASUS PC Probe II ASUS Update Anti-Virus |
Other features
| Specification | Value |
|---|---|
| Controller interface type | JMicron JMB363 PATA & SATA |
| Azalia Digital Header (ADH) connector | 1 |
| Floppy disk drive connector | Yes |
| Special features | - ASUS AI Gear - ASUS AI Nap - ASUS Advanced Q-Fan - ASUS Q-Connector - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - ASUS C.P.R. - ASUS MyLogo 2 |
| Manageability features | WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, RPL |
| RAID controller type | JMicron JMB363 |
