ASUS NCLV-D2/SATA Socket 603 Extended ATX
Model NCLV-D2/SATAPart no. NCLV-D2EAN 4719543137802
23 specifications
- Processor manufacturerIntel
- Number of memory slots6
- Maximum graphics card memory8 MB
- USB 2.0 connectors2
- Motherboard form factorExtended ATX
- Storage temperature (T-T)10 - 35 °C
Overview
- Processor manufacturer
- Intel
- Number of memory slots
- 6
- Maximum graphics card memory
- 8 MB
- USB 2.0 connectors
- 2
- Motherboard form factor
- Extended ATX
- Storage temperature (T-T)
- 10 - 35 °C
- Brand
- ASUS
- Category
- Motherboard
- Model
- NCLV-D2/SATA
- Part numbers
- NCLV-D2, NCLV-D2/SATA, 90-MSVA45-G0UAY
- EAN / UPC
- 4719543137802, 610839130962, 610839137800
- Also known as
- ASUS NCLV-D2/SATA Socket 603 Extended ATX
Specifications
23 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | Socket 603 |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 6 |
| Maximum internal memory | 12 GB |
Graphics
| Specification | Value |
|---|---|
| Maximum graphics card memory | 8 MB |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 2 |
| Number of SATA connectors | 2 |
| Front panel audio connector | Yes |
| ATX Power connector (24-pin) | Yes |
| CPU fan connector | Yes |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| eSATA ports quantity | 1 |
| PS/2 ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking features | Broadcom BCM5721 PCI-E Gb LAN, Broadcom BCM5705E Gb LAN |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | Extended ATX |
| Power source type | ATX |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 1 x PCI-E x 8 2 x PCI- x 64bit/66MHz 2 x PCI 33MHz/32 bits/5V 120P 1 x BMC: Mini-PCI (ASMB2 Card) |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | 10 - 35 °C |
| Operating temperature (T-T) | -40 - 70 °C |
Other features
| Specification | Value |
|---|---|
| Floppy disk drive connector | Yes |
| Graphics controller | ATI RAGE-XL |
