ASUS Maximus II GENE

ASUS Maximus II GENE

Model Maximus II GENEPart no. 90-MIB8G0-G0EAY00ZEAN 4719543170892

46 specifications
  • Processor manufacturerIntel
  • Number of memory slots4
  • RAID levels0, 1, 5, 10
  • USB 2.0 connectors3
  • USB 2.0 ports quantity6
  • Networking featuresGigabit LAN
See all specifications

Overview

Processor manufacturer
Intel
Number of memory slots
4
RAID levels
0, 1, 5, 10
USB 2.0 connectors
3
USB 2.0 ports quantity
6
Networking features
Gigabit LAN
Brand
ASUS
Category
Motherboard
Model
Maximus II GENE
Part numbers
90-MIB8G0-G0EAY00Z, MAXIMUSII/GENE, 90MIB8G0G0EAY00Z, MAXIMUS II GENE
EAN / UPC
4719543170892, 610839170890
Also known as
ASUS Maximus II GENE LGA 775 (Socket T) micro ATX

Specifications

46 specifications in 12 groups

Processor

Processor manufacturerIntel
Processor socketLGA 775 (Socket T)
Compatible processor seriesIntel® Celeron®, Intel® Celeron® Dual-Core, Intel® Pentium® Dual-Core
Maximum number of SMP processors1

Memory

Number of memory slots4
ECC сompatibilityNon-ECC
Maximum internal memory16 GB

Storage controllers

RAID levels0, 1, 5, 10

Internal I/O

USB 2.0 connectors3
Number of SATA connectors7
Number of Parallel ATA connectors1
S/PDIF out connectorYes
Front panel audio connectorYes
CD/AUX audio inYes
ATX Power connector (24-pin)Yes
Number of EATX power connectors1
CPU fan connectorYes
Number of chassis fan connectors4
Chassis intrusion connectorYes

Rear panel I/O ports

USB 2.0 ports quantity6
Ethernet LAN (RJ-45) ports1
eSATA ports quantity1
PS/2 ports quantity1
Firewire (IEEE 1394) ports1
VGA (D-Sub) ports quantity0
HDMI ports quantity0
DVI-D ports quantity0
Headphone outputs1
Microphone inYes
S/PDIF out portYes

Network

Networking featuresGigabit LAN

Features

Motherboard form factormicro ATX
Audio output channels7.1 channels
Power source typeATX

Expansion slots

PCI Express x1 slots1
PCI Express x16 slots2
PCI slots1
Expansion slots2 x thermal sensor, 1 x LCD Poster, 1 x En/Dis-able Clr CMOS

BIOS

BIOS typeAMI
BIOS memory size16 Mbit

Weight & dimensions

Width244 mm
Depth244 mm

Packaging content

Drivers includedYes
Bundled software- Sound Blaster X-Fi Utility - Futuremark 3DMark 06 Advanced Edition - Kaspersky Anti-Virus - ASUS TurboV utility - ASUS PC Probe II - ASUS Update - ASUS AI Suite

Other features

Controller 2nd interface typeJMicron JMB363 PATA/SATA
Controller interface typeIntel ICH10R SATA
