ASUS M5A78L-M LE

ASUS M5A78L-M LE

Model M5A78L-M LEPart no. 90-MIBGD0-G0UAY00ZEAN 5711045475535

60 specifications
  • Processor manufacturerAMD
  • Supported memory typesDDR3-SDRAM
  • Supported storage drive interfacesSATA, SATA II
  • Maximum graphics card memory1024 MB
  • USB 2.0 connectors4
  • Component forPC
See all specifications

Overview

Processor manufacturer
AMD
Supported memory types
DDR3-SDRAM
Supported storage drive interfaces
SATA, SATA II
Maximum graphics card memory
1024 MB
USB 2.0 connectors
4
Component for
PC
Brand
ASUS
Category
Motherboard
Model
M5A78L-M LE
Part numbers
90-MIBGD0-G0UAY00Z, M5A78L-M LE, 90-MIBGD0-G0EAY00Z
EAN / UPC
5711045475535
Also known as
ASUS M5A78L-M LE AMD 760G Socket AM3 micro ATX

Specifications

60 specifications in 12 groups

Processor

Processor manufacturerAMD
Processor socketSocket AM3
Compatible processor seriesAMD Phenom II X2
System bus rate5.2 GT/s
Processor thermal power (max)95 W

Memory

Supported memory typesDDR3-SDRAM
Number of memory slots2
Memory slots typeDIMM
Memory channelsDual-channel
ECC сompatibilityECC & Non-ECC
Supported memory clock speeds1066,1333,1600,1866 MHz
Maximum internal memory8 GB
Supported memory module capacities1GB, 2GB, 4GB, 512MB

Storage controllers

Supported storage drive interfacesSATA, SATA II
RAID levels0, 1, 10, JBOD

Graphics

Maximum graphics card memory1024 MB
Parallel processing technology supportNot supported
On-board graphics cardYes
Graphics card familyAMD
Graphics cardRadeon 3000

Internal I/O

USB 2.0 connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
Number of SATA III connectors0
Number of SATA II connectors6
Number of Parallel ATA connectors0
S/PDIF out connectorYes
Front panel audio connectorYes
Number of EATX power connectors1
CPU fan connectorYes
Number of chassis fan connectors1
Chassis intrusion connectorYes
Number of COM connectors1

Rear panel I/O ports

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Ethernet LAN (RJ-45) ports1
eSATA ports quantity0
PS/2 ports quantity2
Firewire (IEEE 1394) ports0
VGA (D-Sub) ports quantity1
HDMI ports quantity0
DVI-D ports quantity1
Headphone outputs3
Parallel ports quantity1

Features

Component forPC
Motherboard form factormicro ATX
Motherboard chipset familyAMD
Motherboard chipsetAMD 760G
Audio output channels5.1 channels
Power source typeATX
Compatible operating systemsWindows

Expansion slots

PCI Express x1 slots1
PCI Express x16 slots1
PCI slots2

BIOS

BIOS typeAMI
BIOS memory size16 Mbit
ACPI version2.0a

Weight & dimensions

Width244 mm
Depth208 mm

Packaging content

Cables includedSATA

Other features

Controller interface typeRealtek 8111E
