ASUS M4A785-M AMD

ASUS M4A785-M AMD

785G Socket AM2+ micro ATX

Model M4A785-MPart no. 90-MIBB10-G0EAY00ZEAN 4719543172865

52 specifications
  • Processor manufacturerAMD
  • Number of memory slots4
  • Supported storage drive interfacesSATA II
  • Maximum graphics card memory512 MB
  • USB 2.0 connectors3
  • USB 2.0 ports quantity6
See all specifications

Overview

Processor manufacturer
AMD
Number of memory slots
4
Supported storage drive interfaces
SATA II
Maximum graphics card memory
512 MB
USB 2.0 connectors
3
USB 2.0 ports quantity
6
Brand
ASUS
Category
Motherboard
Model
M4A785-M
Part numbers
90-MIBB10-G0EAY00Z, 90-MIBB10-G0EAY0
EAN / UPC
4719543172865
Also known as
ASUS M4A785-M AMD 785G Socket AM2+ micro ATX

Specifications

52 specifications in 12 groups

Processor

Processor manufacturerAMD
Processor socketSocket AM2+

Memory

Number of memory slots4
ECC сompatibilityECC & Non-ECC
Maximum internal memory16 GB

Storage controllers

Supported storage drive interfacesSATA II
RAID levels0, 1, 1+0, JBOD

Graphics

Maximum graphics card memory512 MB
Parallel processing technology supportHybrid CrossFireX
On-board graphics cardYes
Graphics cardRadeon HD 4200

Internal I/O

USB 2.0 connectors3
Number of SATA connectors6
Number of Parallel ATA connectors1
S/PDIF out connectorYes
Front panel audio connectorYes
ATX Power connector (24-pin)Yes
CPU fan connectorYes
Number of chassis fan connectors1
Chassis intrusion connectorYes
Number of COM connectors1

Rear panel I/O ports

USB 2.0 ports quantity6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Ethernet LAN (RJ-45) ports1
eSATA ports quantity0
PS/2 ports quantity1
Firewire (IEEE 1394) ports0
VGA (D-Sub) ports quantity1
HDMI ports quantity1
DVI-D ports quantity1
Headphone outputs6
Microphone inYes
S/PDIF out portYes

Network

LAN controllerRealtek RTL8112L
Networking featuresGigabit Ethernet

Features

Component forPC
Motherboard form factormicro ATX
Motherboard chipset familyAMD
Motherboard chipsetAMD 785G
Audio output channels7.1 channels
Power source typeATX

Expansion slots

PCI Express x1 slots1
PCI Express x16 slots1
PCI slots2

BIOS

BIOS typeAMI
BIOS memory size64 Mbit
ACPI version2.0a

Weight & dimensions

Width244 mm
Depth244 mm

Other features

Controller 2nd interface typeIDE
Controller interface typeSATA
Audio outputVT1708S
