ASUS M3N-HT Deluxe/Mempipe
Model M3N-HT Deluxe/MempipePart no. M3N-HT DELUXE/MEMPIPE
38 specifications
- Processor manufacturerAMD
- Number of memory slots4
- RAID levels0, 1, 0+1, 5, JBOD
- Maximum graphics card memory512 MB
- USB 2.0 connectors3
- Motherboard form factorATX
Overview
- Processor manufacturer
- AMD
- Number of memory slots
- 4
- RAID levels
- 0, 1, 0+1, 5, JBOD
- Maximum graphics card memory
- 512 MB
- USB 2.0 connectors
- 3
- Motherboard form factor
- ATX
- Brand
- ASUS
- Category
- Motherboard
- Model
- M3N-HT Deluxe/Mempipe
- Part numbers
- M3N-HT DELUXE/MEMPIPE, 90-MIB3H1-G0AAY00Z
- Also known as
- ASUS M3N-HT Deluxe/Mempipe Socket AM2 ATX
Specifications
38 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor socket | Socket AM2 |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 4 |
| ECC сompatibility | ECC & Non-ECC |
| Maximum internal memory | 8 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1, 0+1, 5, JBOD |
Graphics
| Specification | Value |
|---|---|
| Maximum graphics card memory | 512 MB |
| Graphics card | GeForce 8 |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 3 |
| Number of SATA connectors | 6 |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| CD/AUX audio in | Yes |
| Power fan connector | Yes |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 1 |
| Chassis intrusion connector | Yes |
| Number of COM connectors | 1 |
| Number of IEEE1394 connectors | 2 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| eSATA ports quantity | 1 |
| PS/2 ports quantity | 1 |
| Firewire (IEEE 1394) ports | 0 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DVI-D ports quantity | 0 |
| S/PDIF out port | Yes |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | ATX |
| Audio chip | ADI AD1988B |
| Audio output channels | 7.1 channels |
| Power source type | ATX |
| Compatible operating systems | Windows Vista, Windows XP |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 slots | 1 |
| PCI Express x16 slots | 3 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 305 mm |
| Depth | 244 mm |
Other features
| Specification | Value |
|---|---|
| RAID controller type | Marvell 6111 SATA |
What people say
Reviews & ratings
ASUS M3N-HT Deluxe/Mempipe
No reviews yet
Be the first to tell others how ASUS M3N-HT Deluxe/Mempipe works for you.
Write the first review- Every rating countsLow ratings are never hidden, removed or pushed down.
- Written by people, never paidNo incentives, no edits — only spam and abuse are removed.
- Private by designOnly the name you choose is shown. No account, no e-mail, nothing tracked.
Compare ASUS M3N-HT Deluxe/Mempipe
All motherboard comparisons- ASUS M3N-HT Deluxe/Mempipe vsASUS P5E3 Premium/WiFi-APCompare specs
- ASUS M3N-HT Deluxe/Mempipe vsASUS P5E3 WS ProfessionalCompare specs
- ASUS M3N-HT Deluxe/Mempipe vsASUS M3N-HT Deluxe/HDMICompare specs
- ASUS M3N-HT Deluxe/Mempipe vsASUS L1N64-SLI WS/BCompare specs
