ASUS KFSN5-D/IST Socket F (1207) SSI EEB
Model KFSN5-D/ISTPart no. 90-MSVCA5-G0UAY00ZEAN 4719543172469
27 specifications
- Processor manufacturerAMD
- Maximum internal memory64 GB
- RAID levels0, 1, 5, 10, JBOD
- USB 2.0 connectors3
- USB 2.0 ports quantity2
- Motherboard form factorSSI EEB
Overview
- Processor manufacturer
- AMD
- Maximum internal memory
- 64 GB
- RAID levels
- 0, 1, 5, 10, JBOD
- USB 2.0 connectors
- 3
- USB 2.0 ports quantity
- 2
- Motherboard form factor
- SSI EEB
- Brand
- ASUS
- Category
- Motherboard
- Model
- KFSN5-D/IST
- Part number
- 90-MSVCA5-G0UAY00Z
- EAN / UPC
- 4719543172469
- Also known as
- ASUS KFSN5-D/IST Socket F (1207) SSI EEB
Specifications
27 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor socket | Socket F (1207) |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory | 64 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1, 5, 10, JBOD |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 3 |
| Number of SATA connectors | 6 |
| ATX Power connector (24-pin) | Yes |
| Number of EATX power connectors | 2 |
| CPU fan connector | Yes |
| Chassis intrusion connector | Yes |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| eSATA ports quantity | 0 |
| PS/2 ports quantity | 1 |
| Firewire (IEEE 1394) ports | 0 |
| VGA (D-Sub) ports quantity | 1 |
| DVI-D ports quantity | 0 |
| Serial ports quantity | 1 |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | SSI EEB |
| Certification | - US (FCC, CFR47 Part 15, Class B) - Europe (CE, EN55022 & EN55024) |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x8 slots | 1 |
| PCI Express x16 slots | 3 |
| PCI slots | 1 |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 20 - 90% |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | ASWM2.0 |
