ASUS F1A55 AMD A55 Socket FM1 ATX

ASUS F1A55 AMD A55 Socket FM1 ATX

Model F1A55Part no. 90-MIBH20-G0EAY0DZEAN 4719543182000

70 specifications
  • Memory0 GB
  • Processor manufacturerAMD
  • Number of memory slots4
  • RAID levels0, 1, 10, JBOD
  • On-board graphics cardYes
  • USB 2.0 connectors3
See all specifications

Overview

Memory
0 GB
Processor manufacturer
AMD
Number of memory slots
4
RAID levels
0, 1, 10, JBOD
On-board graphics card
Yes
USB 2.0 connectors
3
Brand
ASUS
Category
Motherboard
Model
F1A55
Part numbers
90-MIBH20-G0EAY0DZ, F1A55
EAN / UPC
4719543182000
Also known as
ASUS F1A55 AMD A55 Socket FM1 ATX

Specifications

70 specifications in 13 groups

Processor

Processor manufacturerAMD
Processor socketSocket FM1
Compatible processor seriesAMD A, AMD E2

Memory

Number of memory slots4
ECC сompatibilityNon-ECC
Internal memory0 GB
Supported memory clock speeds1066,1333,1600,1866 MHz
Maximum internal memory64 GB
Supported memory module capacities16GB

Storage controllers

RAID levels0, 1, 10, JBOD

Graphics

On-board graphics cardYes
Graphics card familyAMD
Graphics cardRadeon HD 6000

Internal I/O

USB 2.0 connectors3
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
Number of SATA II connectors6
Number of Parallel ATA connectors0
S/PDIF out connectorYes
Front panel audio connectorYes
ATX Power connector (24-pin)Yes
Number of EATX power connectors1
Power fan connectorYes
CPU fan connectorYes
Number of chassis fan connectors2
Number of COM connectors1
Number of IEEE1394 connectors0
TPM connectorNo

Rear panel I/O ports

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LAN (RJ-45) ports1
eSATA ports quantity0
PS/2 ports quantity6
Firewire (IEEE 1394) ports0
VGA (D-Sub) ports quantity0
HDMI ports quantity0
DVI-D ports quantity0
DVI-I ports quantity0
DisplayPorts quantity0
Headphone outputs1
Microphone inYes
S/PDIF out portYes
Digital audio optical out0
COM ports quantity0
Parallel ports quantity0
Serial ports quantity0
WiFi-AP antenna jack0
Modem (RJ-11) ports0

Network

Ethernet interface typeGigabit Ethernet
LAN controllerRealtek RTL8111E
BluetoothNo

Features

Component forPC
Motherboard form factorATX
Motherboard chipsetAMD A55
Audio chipRealtek ALC887
Audio output channels7.1 channels
Power source typeATX

Expansion slots

PCI Express x1 slots2
PCI Express x16 slots2
PCI Express slots version2.0
PCI slots3

BIOS

BIOS typeUEFI
BIOS memory size32 Mbit
ACPI version2.0a

Weight & dimensions

Width305 mm
Depth224 mm

Packaging content

Cables includedSATA
Drivers includedYes

Other features

PCI Express power connectors (6-pin)0
Controller interface typeSATA
IPMI 2.0 slotNo
