ASUS DSEB-DG Intel® 5400 LGA 771 (Socket J) SSI EEB
Model DSEB-DGPart no. 90-MSVC30-G0UAY00ZEAN 610839158553
25 specifications
- Processor manufacturerIntel
- Maximum internal memory64 GB
- RAID levels0, 1, 5, 10
- USB 2.0 connectors1
- USB 2.0 ports quantity2
- LAN controllerIntel® 82563EB
Overview
- Processor manufacturer
- Intel
- Maximum internal memory
- 64 GB
- RAID levels
- 0, 1, 5, 10
- USB 2.0 connectors
- 1
- USB 2.0 ports quantity
- 2
- LAN controller
- Intel® 82563EB
- Brand
- ASUS
- Category
- Motherboard
- Model
- DSEB-DG
- Part numbers
- 90-MSVC30-G0UAY00Z, DSEB-DG
- EAN / UPC
- 610839158553, 4719543158555
- Also known as
- ASUS DSEB-DG Intel® 5400 LGA 771 (Socket J) SSI EEB
Specifications
25 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | LGA 771 (Socket J) |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory | 64 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1, 5, 10 |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 1 |
| Number of SATA connectors | 8 |
| ATX Power connector (24-pin) | Yes |
| Power fan connector | Yes |
| CPU fan connector | Yes |
| Number of chassis fan connectors | 1 |
| Chassis intrusion connector | Yes |
| Number of COM connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 4 |
| PS/2 ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| LAN controller | Intel® 82563EB |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | SSI EEB |
| Motherboard chipset | Intel® 5400 |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 10 - 35 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 305 mm |
| Depth | 330 mm |
Other features
| Specification | Value |
|---|---|
| RAID controller type | SATA |
