ASUS Bundkort AM2 nForce 590 SLI 4*DDR2 800
Model Bundkort AM2 nForce 590 SLI 4*DDR2 800Part no. CROSSHAIR
36 specifications
- Processor manufacturerIntel
- Number of memory slots4
- RAID levels0, 1, 0+1
- USB 2.0 connectors3
- Networking featuresNVIDIA DualNet
- Motherboard form factorATX
Overview
- Processor manufacturer
- Intel
- Number of memory slots
- 4
- RAID levels
- 0, 1, 0+1
- USB 2.0 connectors
- 3
- Networking features
- NVIDIA DualNet
- Motherboard form factor
- ATX
- Brand
- ASUS
- Category
- Motherboard
- Model
- Bundkort AM2 nForce 590 SLI 4*DDR2 800
- Part numbers
- CROSSHAIR, 90MIB050-G0EAY
- Also known as
- ASUS Bundkort AM2 nForce 590 SLI 4*DDR2 800 Socket AM2 ATX
Specifications
36 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor socket | Socket AM2 |
Memory
| Specification | Value |
|---|---|
| Number of memory slots | 4 |
| ECC сompatibility | ECC & Non-ECC |
| Maximum internal memory | 8 GB |
Storage controllers
| Specification | Value |
|---|---|
| RAID levels | 0, 1, 0+1 |
Internal I/O
| Specification | Value |
|---|---|
| USB 2.0 connectors | 3 |
| Number of SATA connectors | 6 |
| S/PDIF out connector | Yes |
| Front panel audio connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Power fan connector | Yes |
| CPU fan connector | Yes |
| Chassis intrusion connector | Yes |
| Number of IEEE1394 connectors | 1 |
Rear panel I/O ports
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| eSATA ports quantity | 2 |
| PS/2 ports quantity | 2 |
| Firewire (IEEE 1394) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| S/PDIF out port | Yes |
Network
| Specification | Value |
|---|---|
| Networking features | NVIDIA DualNet |
Features
| Specification | Value |
|---|---|
| Motherboard form factor | ATX |
| Audio chip | ADI AD1988B |
| Audio output channels | 7.1 channels |
| Power source type | ATX |
| Overclocking features | ASUS AI NOS ASUS PEG Link ASUS O.C. Profile ASUS C.P.R. Extreme Tweaker ASUS AI BU |
Expansion slots
| Specification | Value |
|---|---|
| Expansion slots | 2 x PCI Express x16 1 x PCI Express x4 3 x PCI 2.2 |
BIOS
| Specification | Value |
|---|---|
| BIOS type | AWARD |
| BIOS memory size | 64 Mbit |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 305 mm |
| Depth | 245 mm |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | ASUS PC Probe II ASUS Update ASUS AI Booster Futuremark 3DMark06 AE NVIDIA MediaShield RAID Kaspersky AntiVirus |
Other features
| Specification | Value |
|---|---|
| Manageability features | WOL (PME) WOR (PME) PXE |
