ASUS AT4NM10T-I motherboard Intel® NM10 Express NA (integrated CPU) mini ITX

ASUS AT4NM10T-I motherboard Intel® NM10 Express NA (integrated CPU) mini ITX

Model AT4NM10T-IEAN 610839179046

58 specifications
  • ProcessorD425
  • Processor manufacturerIntel
  • Supported memory typesDDR3-SDRAM
  • Supported storage drive interfacesSATA
  • Maximum graphics card memory256 MB
  • USB 2.0 connectors1
See all specifications

Overview

Processor
D425
Processor manufacturer
Intel
Supported memory types
DDR3-SDRAM
Supported storage drive interfaces
SATA
Maximum graphics card memory
256 MB
USB 2.0 connectors
1
Brand
ASUS
Category
Motherboard
Model
AT4NM10T-I
Part number
AT4NM10T-I
EAN / UPC
610839179046, 4719543179048
Also known as
ASUS AT4NM10T-I motherboard Intel® NM10 Express NA (integrated CPU) mini ITX

Specifications

58 specifications in 11 groups

Processor

Processor manufacturerIntel
Processor socketNA (integrated CPU)
Compatible processor seriesIntel Atom®
Processor modelD425

Memory

Supported memory typesDDR3-SDRAM
Number of memory slots2
Memory slots typeSO-DIMM
Memory channelsSingle-channel
ECC сompatibilityNon-ECC
Supported memory clock speeds800 MHz
Maximum internal memory4 GB
Unbuffered memoryYes

Storage controllers

Supported storage drive interfacesSATA

Graphics

Maximum graphics card memory256 MB
Parallel processing technology supportNot supported
On-board graphics cardYes
Graphics card familyIntel
Graphics cardGMA 3150

Internal I/O

USB 2.0 connectors1
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
Number of SATA III connectors0
Number of SATA II connectors2
S/PDIF out connectorYes
Front panel audio connectorYes
ATX Power connector (24-pin)Yes
CPU fan connectorYes
Number of chassis fan connectors1
Chassis intrusion connectorYes
Peripheral (Molex) power connectors (4-pin)1
Number of COM connectors1
Parallel connectorYes
TPM connectorYes

Rear panel I/O ports

USB 2.0 ports quantity6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Ethernet LAN (RJ-45) ports1
eSATA ports quantity2
PS/2 ports quantity1
Firewire (IEEE 1394) ports0
VGA (D-Sub) ports quantity1
HDMI ports quantity0
DVI-D ports quantity0
Headphone outputs2
Microphone inYes
COM ports quantity1

Network

Ethernet interface typeGigabit Ethernet
LAN controllerRealtek RTL8111E
Networking featuresGigabit Ethernet

Features

Component forPC
Motherboard form factormini ITX
Motherboard chipset familyIntel
Motherboard chipsetIntel® NM10 Express
Audio chipVIA VT1705S
Audio output channels5.1 channels
Power source typeATX

Expansion slots

PCI Express x4 slots1

BIOS

BIOS typeAMI

Weight & dimensions

Width170 mm
Depth170 mm
