TD2760 computer monitor
68.6 cm (27") 1920 x 1080 pixels Full HD LED Touchscreen Multi-user Black
Model TD2760EAN 766907002775
100 specifications Checked today
- Display68.6 cm (27")
- Resolution1920 x 1080 pixels
- Energy classE
- Weight7.9 kg
- ColourBlack
- NVIDIA G-SYNCNo
Overview
- Display
- 68.6 cm (27")
- Resolution
- 1920 x 1080 pixels
- Energy class
- E
- Weight
- 7.9 kg
- Colour
- Black
- NVIDIA G-SYNC
- No
- Brand
- Viewsonic
- Category
- Monitor
- Model
- TD2760
- Part number
- TD2760
- EAN / UPC
- 766907002775, 7669070027756
- Also known as
- Viewsonic TD2760 computer monitor 68.6 cm (27") 1920 x 1080 pixels Full HD LED Touchscreen Multi-user Black
Specifications
100 specifications in 14 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 68.6 cm (27") |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Touchscreen | Yes |
| HD type | Full HD |
| Panel type | VA |
| LED backlight | Yes |
| Backlight type | LED |
| Touchscreen type | Multi-user |
| Touchscreen technology | Projected capacitive system |
| Touch technology | Multi-touch |
| Number of simultaneous touchpoints | 10 |
| Display brightness | 300 cd/m² |
| Response time | 6 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Aspect ratio | 16:9 |
| Contrast ratio (typical) | 3000:1 |
| Contrast ratio (dynamic) | 50000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.311 x 0.311 mm |
| Horizontal scan range | 15 - 90 kHz |
| Vertical scan range | 50 - 76 Hz |
| Viewable size, horizontal | 59.8 cm |
| Viewable size, vertical | 33.6 cm |
| Display diagonal (metric) | 68.58 cm |
| Surface hardness | 6H |
| Separate H/V sync | Yes |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Built-in camera | No |
| Built-in microphone | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Glass thickness | 1.88 mm |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| Number of USB Type-B upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| Audio input | 1 |
| Audio output | 1 |
| HDCP | Yes |
| RS-232 ports | 1 |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Wall mountable | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Tilt adjustment | Yes |
| Tilt angle range | -4 - 90° |
| On Screen Display (OSD) | Yes |
| Number of OSD languages | 14 |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 19 kWh |
| Power consumption (typical) | 26 W |
| Power consumption (standby) | 0.3 W |
| Power consumption (off) | 0.2 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power supply type | AC |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 660 mm |
| Depth (with stand) | 239 mm |
| Height (with stand) | 443 mm |
| Weight (with stand) | 7.9 kg |
| Width (without stand) | 660 mm |
| Depth (without stand) | 58 mm |
| Height (without stand) | 410 mm |
| Weight (without stand) | 5.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 753 mm |
| Package depth | 204 mm |
| Package height | 525 mm |
| Package weight | 10.2 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Power, VGA, HDMI, USB, Audio |
| Quick start guide | Yes |
Other features
| Specification | Value |
|---|---|
| Weight | 7.9 kg |
| Mean time between failures (MTBF) | 30000 h |
| Certification | MX-CoC, Mexico Energy, CE, CE EMC, CB |
| Supplied AC adapter type | AC |
Technical details
| Specification | Value |
|---|---|
| Native refresh rate | 60 Hz |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 1 pc(s) |
| Pallet gross width | 120 cm |
| Pallet gross length | 100 cm |
| Pallet gross height | 2.24 m |
| Harmonized System (HS) code | 8528521000 |
Energy efficiency
ENERGY STAR certified
Displays · model VS17780 · certified Jan 9, 2020 · United States, Switzerland, Taiwan, Japan, Canada
| Measurement | Value |
|---|---|
| On-mode power | 19.05 W |
| Sleep-mode power | 0.18 W |
| Off-mode power | 0.11 W |
