MultiSync E224F computer monitor
55.9 cm (22") 1920 x 1080 pixels Full HD LCD Black
Model E224FPart no. DDE224FEAN 074000705104
68 specifications Checked today
- Display55.9 cm (22")
- Resolution1920 x 1080 pixels
- Energy classD
- ColourBlack
- Built-in speaker(s)Yes
- Market positioningConsumer
Overview
- Display
- 55.9 cm (22")
- Resolution
- 1920 x 1080 pixels
- Energy class
- D
- Colour
- Black
- Built-in speaker(s)
- Yes
- Market positioning
- Consumer
- Brand
- Sharp
- Category
- Monitor
- Model
- E224F
- Part number
- DDE224F
- EAN / UPC
- 074000705104, 4550556177603
- Also known as
- Sharp MultiSync E224F computer monitor 55.9 cm (22") 1920 x 1080 pixels Full HD LCD Black
Specifications
68 specifications in 9 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 55.9 cm (22") |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Touchscreen | No |
| HD type | Full HD |
| Panel type | VA |
| LED backlight | Yes |
| Backlight type | W-LED |
| Display brightness (typical) | 240 cd/m² |
| Response time | 6 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Supported video modes | 1080p |
| Contrast ratio (typical) | 3000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.275 x 0.275 mm |
| Vertical scan range | 50 - 75 Hz |
| Display diagonal (metric) | 55 cm |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 2 W |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Consumer |
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Wall mountable | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 12 cm |
| Pivot | Yes |
| Pivot angle | -90 - 90° |
| Swivelling | Yes |
| Swivel angle range | -170 - 170° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 25° |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | D |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 12 kWh |
| Power consumption (typical) | 14 W |
| Power consumption (standby) | 0.2 W |
| Power consumption (off) | 0.2 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 493.2 mm |
| Depth (with stand) | 233.2 mm |
| Height (with stand) | 483.4 mm |
| Weight (with stand) | 5.2 kg |
| Weight (without stand) | 3.1 kg |
| Bezel width (side) | 2.5 mm |
| Bezel width (top) | 2.5 mm |
| Bezel width (bottom) | 1.68 cm |
Technical details
| Specification | Value |
|---|---|
| Native refresh rate | 60 Hz |
