Samsung SyncMaster 540B
Model SyncMaster 540BPart no. LS15HABTS
25 specifications Checked 2 days ago
- Display38.1 cm (15")
- Resolution1024 x 768 pixels
- ColourSilver
- I/O portsVGA (15 D-sub) DVI-D
- Panel mounting interface75 x 75 mm
- Power consumption (typical)25 W
Overview
- Display
- 38.1 cm (15")
- Resolution
- 1024 x 768 pixels
- Colour
- Silver
- I/O ports
- VGA (15 D-sub) DVI-D
- Panel mounting interface
- 75 x 75 mm
- Power consumption (typical)
- 25 W
- Brand
- Samsung
- Category
- Monitor
- Model
- SyncMaster 540B
- Part number
- LS15HABTS
- Also known as
- Samsung SyncMaster 540B computer monitor 38.1 cm (15") 1024 x 768 pixels Silver
Specifications
25 specifications in 8 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 38.1 cm (15") |
| Display resolution | 1024 x 768 pixels |
| Touchscreen | No |
| Display brightness (typical) | 250 cd/m² |
| Response time | 8 ms |
| Contrast ratio (typical) | 450:1 |
| Viewing angle, horizontal | 140° |
| Viewing angle, vertical | 140° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.297 |
| Horizontal scan range | 30 - 61 kHz |
| Vertical scan range | 56 - 75 Hz |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
Ports & interfaces
| Specification | Value |
|---|---|
| I/O ports | VGA (15 D-sub) DVI-D |
Ergonomics
| Specification | Value |
|---|---|
| Panel mounting interface | 75 x 75 mm |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 25 W |
| Power consumption (standby) | 1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (without stand) | 338 mm |
| Depth (without stand) | 180 mm |
| Height (without stand) | 334 mm |
| Weight (without stand) | 3.7 kg |
Packaging content
| Specification | Value |
|---|---|
| Bundled software | S/W Pivot Software |
Other features
| Specification | Value |
|---|---|
| Certification | TCO '99 |
| Bundled hardware | VGA cable |
| Supplied AC adapter type | LCD |
