SM204B computer monitor
51 cm (20.1") 1600 x 1200 pixels
Model SM204BPart no. LS20BRDTS-BRDBSQ/EDC/ESQ
33 specifications Checked today
- Display51 cm (20.1")
- Resolution1600 x 1200 pixels
- Built-in speaker(s)No
- VGA (D-Sub) ports quantity1
- Panel mounting interface100 x 100 mm
- Power consumption (typical)63 W
Overview
- Display
- 51 cm (20.1")
- Resolution
- 1600 x 1200 pixels
- Built-in speaker(s)
- No
- VGA (D-Sub) ports quantity
- 1
- Panel mounting interface
- 100 x 100 mm
- Power consumption (typical)
- 63 W
- Brand
- Samsung
- Category
- Monitor
- Model
- SM204B
- Part numbers
- LS20BRDTS-BRDBSQ/EDC/ESQ, LS20BRDTS-BRDB/ESQ
- Also known as
- Samsung SM204B computer monitor 51 cm (20.1") 1600 x 1200 pixels
Specifications
33 specifications in 8 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 51 cm (20.1") |
| Display resolution | 1600 x 1200 pixels |
| Touchscreen | No |
| Display brightness (typical) | 300 cd/m² |
| Response time | 5 ms |
| Contrast ratio (typical) | 800:1 |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 160° |
| Pixel pitch | 0.255 x 0.255 mm |
| Sync-on-green (SOG) | Yes |
| Separate H/V sync | Yes |
| Composite sync | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| DVI-D ports quantity | 1 |
Ergonomics
| Specification | Value |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Plug and Play | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 63 W |
| Power consumption (standby) | 2 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 444 mm |
| Depth (with stand) | 200 mm |
| Height (with stand) | 427.6 mm |
| Width (without stand) | 444 mm |
| Depth (without stand) | 74.5 mm |
| Height (without stand) | 344 mm |
| Weight (without stand) | 7.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 424 mm |
| Package depth | 235 mm |
| Package height | 551 mm |
| Package weight | 9 kg |
Other features
| Specification | Value |
|---|---|
| TV tuner integrated | No |
| Supplied AC adapter type | LCD |
