S80UH computer monitor

68.6 cm (27") 3840 x 2160 pixels 4K Ultra HD LCD Black

Model S80UHPart no. LS32H802UAEXXYEAN 8806099141837

93 specifications Checked today

Display68.6 cm (27")
Resolution3840 x 2160 pixels
Energy classF
ColourBlack
NVIDIA G-SYNCNo
Market positioningOffice

See all specifications

Overview

Display: 68.6 cm (27")
Resolution: 3840 x 2160 pixels
Energy class: F
Colour: Black
NVIDIA G-SYNC: No
Market positioning: Office

Brand: Samsung
Category: Monitor
Model: S80UH
Part numbers: LS32H802UAEXXY, LS32H804UAUXXE, LS27H804UAUXXE, LS27H800UAUXEN, LS32H800UAUXEN, LS32H804UAUXEN +2 more
EAN / UPC: 8806099141837, 8806099141844, 8806099141813, 8806099163136 +2 more
Also known as: Samsung S80UH computer monitor 68.6 cm (27") 3840 x 2160 pixels 4K Ultra HD LCD Black

Specifications

93 specifications in 14 groups

Display

Specification	Value
Display diagonal	68.6 cm (27")
Display resolution	3840 x 2160 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	4K Ultra HD
Panel type	IPS
Display brightness (typical)	350 cd/m²
Display brightness (min)	280 cd/m²
Response time	5 ms
Response time measurement type	GTG (Gray to Gray)
Screen shape	Flat
Contrast ratio (typical)	1000:1
Dynamic contrast ratio marketing name	Mega Infinity DCR
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colours
Viewable size, horizontal	59.7 cm
Viewable size, vertical	33.6 cm
Display diagonal (metric)	68 cm
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
sRGB coverage (typical)	99%

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Flicker-free technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Office
Product colour	Black
Feet colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of USB Type-B upstream ports quantity	1
USB Type-A downstream ports quantity	3
USB Type-C downstream ports quantity	1
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	90 W
HDMI	Yes
HDMI ports quantity	1
HDMI version	2.0
DisplayPorts quantity	1
DisplayPort out version	1.2
Headphone out	Yes
Built-in KVM switch	Yes
HDCP	Yes
HDCP version	2.2

Network

Specification	Value
Ethernet LAN	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Height adjustment	Yes
Adjustable height (max)	12 cm
Pivot	Yes
Pivot angle	-92 - 92°
Swivelling	Yes
Swivel angle range	-45 - 45°
Tilt adjustment	Yes
Tilt angle range	-3 - 25°
Picture-in-Picture	Yes

Power

Specification	Value
Energy efficiency class (SDR)	F
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	26 kWh
Energy consumption (HDR) per 1000 hours	42 kWh
Power consumption (typical)	26 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 80%

Weight & dimensions

Specification	Value
Width (with stand)	616.3 mm
Depth (with stand)	218 mm
Height (with stand)	560.2 mm
Weight (with stand)	5.3 kg
Width (without stand)	616.3 mm
Depth (without stand)	46 mm
Height (without stand)	366.5 mm
Weight (without stand)	3.9 kg

Packaging data

Specification	Value
Stand type	HAS stand
Package weight	6.8 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	Power, USB Type-C, USB Type-A to USB Type-B
Power cable length	1.5 m

Sustainability

Specification	Value
Sustainability certificates	TCO, EPEAT Silver

Other features

Specification	Value
Picture-by-Picture (PbP)	Yes
Auto source switch+	Yes
Samsung Eye Saver Mode	Yes
Ethernet LAN (RJ-45) ports	1
Eco Saving Plus	Yes
Image size	Yes
Off Timer Plus	Yes
