Samsung 230MXN computer monitor

Samsung 230MXN computer monitor

58.4 cm (23") 1920 x 1080 pixels Full HD Black

Model 230MXNPart no. LH23PTTMBCEAN 8808993463374

78 specifications Checked 4 days ago
  • Display58.4 cm (23")
  • Resolution1920 x 1080 pixels
  • ProcessorAMD Athlon X2
  • Memory1024 MB
  • Storage40 GB
  • OSWindows XP Embedded
See all specifications

Overview

Display
58.4 cm (23")
Resolution
1920 x 1080 pixels
Processor
AMD Athlon X2
Memory
1024 MB
Storage
40 GB
OS
Windows XP Embedded
Brand
Samsung
Category
Monitor
Model
230MXN
Part numbers
LH23PTTMBC, SM-230MXN, LH23PTSMBC/XY, LH23PTSMBC/EN
EAN / UPC
8808993463374
Also known as
Samsung 230MXN computer monitor 58.4 cm (23") 1920 x 1080 pixels Full HD Black

Specifications

78 specifications in 14 groups

Display

Display diagonal58.4 cm (23")
Display resolution1920 x 1080 pixels
Native aspect ratio16:9
TouchscreenNo
HD typeFull HD
Display brightness (typical)300 cd/m²
Response time8 ms
Supported graphics resolutions1920 x 1080 (HD 1080)
Supported video modes1080p
Aspect ratio16:9
Contrast ratio (typical)3000:1
Contrast ratio (dynamic)5000:1
Viewing angle, horizontal178°
Viewing angle, vertical178°
Display number of colours16.78 million colours
Pixel pitch0.2566 x 0.2566 mm
Horizontal scan range30 - 81 kHz
Vertical scan range56 - 85 Hz
Viewable size, horizontal51 cm
Viewable size, vertical28.7 cm
3DNo

Performance

Operating system installedWindows XP Embedded
Windows operating systems supportedYes

Multimedia

Built-in speaker(s)Yes
Number of speakers2
RMS rated power6 W
Built-in cameraNo

Design

Product colourBlack

Ports & interfaces

USB hub version2.0
USB Type-A downstream ports quantity1
VGA (D-Sub) ports quantity1
HDMIYes
HDMI ports quantity1
Headphone outputs1
AC (power) inYes
RS-232 ports1

Network

Ethernet LANYes

Ergonomics

VESA mountingYes
Panel mounting interface100 x 100 mm
Cable lock slotNo
PivotYes
Plug and PlayYes

Power

Power consumption (typical)120 W
Power consumption (standby)5 W
Power consumption (off)1 W
Power consumption (PowerSave)70 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz

Operational conditions

Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)10 - 80%

Weight & dimensions

Width (with stand)557.5 mm
Depth (with stand)73.9 mm
Height (with stand)339 mm
Weight (with stand)7 kg

Packaging data

Package dimensions (WxDxH)640 x 192 x 418 mm
Package width640 mm
Package depth192 mm
Package height418 mm
Package weight8.6 kg

Packaging content

Cables includedVGA
Remote control includedYes
Quick start guideYes
ManualYes

Other features

TV tuner integratedNo
SafetyUL (USA): UL 60950-1CSA (Canada): CSA C22.2 No. 60950-1 TUV (Germany): EN60950-1NEMKO (Norway): EN60950-1 KC (Korea): K60950-1 CCC (China): GB 4943-2001PSB (Singapore): IEC60950-1GOST (Russia): IEC60950-1, EN55022SIQ (Slovenia): IEC60950-1, EN55022PCBC (Poland): IEC60590-1, EN55022NOM (Mexico): NOM-
Ethernet LAN data rates10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports1
CertificationFCC (USA) FCC Part 15, Subpart B class BCE (Europe) EN55022, EN55024VCCI (Japan) V-3 (CISPR22)KCC (Korea):KN22, KN24BSMI (Taiwan): CNS13438 (CISPR22)C-Tick (Australia): AS/NZS3548 (CISPR22) CCC(China):GB 9254-2008, GB 17625.1-2003

Thin Client

Thin client installedYes
Processor familyAMD Athlon X2
Processor model4450e
Processor frequency2.3 GHz
Motherboard chipsetAMD RS780
Motherboard southbridgeAMD SB700
Internal memory1024 MB
Internal memory typeDDR2
HDD capacity40 GB
Pre-installed softwareMagicinfo Pro
