246E8FJAB/11 computer monitor
60.5 cm (23.8") 2560 x 1440 pixels Quad HD LCD Black, Grey
Model 246E8FJAB/11EAN 609585251670
101 specifications Checked today
- Display60.5 cm (23.8")
- Resolution2560 x 1440 pixels
- ColourBlack, Grey
- NVIDIA G-SYNCNo
- Built-in speaker(s)Yes
- Market positioningIndustrial
Overview
- Display
- 60.5 cm (23.8")
- Resolution
- 2560 x 1440 pixels
- Colour
- Black, Grey
- NVIDIA G-SYNC
- No
- Built-in speaker(s)
- Yes
- Market positioning
- Industrial
- Brand
- Philips
- Category
- Monitor
- Model
- 246E8FJAB/11
- Part number
- 246E8FJAB/11
- EAN / UPC
- 609585251670
- Also known as
- Philips 246E8FJAB/11 computer monitor 60.5 cm (23.8") 2560 x 1440 pixels Quad HD LCD Black, Grey
Specifications
101 specifications in 13 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 2560 x 1440 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Touchscreen | No |
| HD type | Quad HD |
| Panel type | IPS |
| LED backlight | Yes |
| Backlight type | W-LED |
| Display brightness (typical) | 300 cd/m² |
| Response time | 4 ms |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 20000000:1 |
| Dynamic contrast ratio marketing name | SmartContrast |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.205 x 0.205 mm |
| Pixel density | 123 ppi |
| Horizontal scan range | 54 - 84 kHz |
| Vertical scan range | 46 - 75 Hz |
| Viewable size, horizontal | 52.6 cm |
| Viewable size, vertical | 29.6 cm |
| Sync-on-green (SOG) | Yes |
| Display diagonal (metric) | 60.5 cm |
| DDC/CI | Yes |
| Colour gamut standard | sRGB, NTSC |
| Colour gamut | 119% |
| sRGB coverage (typical) | 133% |
| NTSC coverage (typical) | 119% |
| Display sRGB | Yes |
| Display panel size | 23.8 inch / 60.5 cm |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | No |
| AMD FreeSync | Yes |
| Component video sync | Separate Sync, Sync-on-green (SOG) |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 6 W |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Industrial |
| Product colour | Black, Grey |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| HDMI version | 1.4 |
| DisplayPort version | 1.2 |
| Headphone out | Yes |
| PC Audio in | Yes |
Ergonomics
| Specification | Value |
|---|---|
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | No |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian |
| Number of OSD languages | 21 |
| Plug and Play | Yes |
| LED indicators | Operation, Stand-by |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 17.89 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | External |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Operating altitude | 0 - 3658 m |
| Non-operating altitude | 0 - 12192 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 541 mm |
| Depth (with stand) | 176 mm |
| Height (with stand) | 421 mm |
| Weight (with stand) | 3.79 kg |
| Width (without stand) | 541 mm |
| Depth (without stand) | 42 mm |
| Height (without stand) | 333 mm |
| Weight (without stand) | 3.29 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 587 mm |
| Package depth | 129 mm |
| Package height | 482 mm |
| Package weight | 5.67 kg |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | TCO |
| Doesn't contain | Mercury |
| Sustainability compliance | Yes |
Other features
| Specification | Value |
|---|---|
| Compatible operating systems | Mac OS X; Windows 10 / 8.1 / 8 / 7 |
| Exterior finish type | Gloss |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS, WEEE |
| Heavy metals free | Hg (mercury) |
| LowBlue mode | Yes |
| Monitor sync input signal | Separate Sync; Sync on Green |
| No flickering | Yes |
| Signal input | VGA (Analog ); DisplayPort 1.2; HDMI 1.4 |
| Mean time between failures (MTBF) | 50000 h |
| Picture enhancement | SmartImage Lite |
| Regulatory Approvals | CE Mark; FCC Class B; TCO Certified; WEEE; CECP; CU; EPA; RCM; PSE; VCCI |
| User controls | Power On/Off; Menu; Volume; Input; SmartImage lite |
Recycling data
| Specification | Value |
|---|---|
| Packaging recyclability rate | 100% |
