E Line LCD monitor with Ultra Wide-Color 246E7QDSW/00

Model 246E7QDSW/00EAN 4058154018354

121 specifications Checked today

Display59.9 cm (23.6")
Resolution1920 x 1080 pixels
Energy classB
ColourWhite
NVIDIA G-SYNCNo
Market positioningHome

See all specifications

Overview

Display: 59.9 cm (23.6")
Resolution: 1920 x 1080 pixels
Energy class: B
Colour: White
NVIDIA G-SYNC: No
Market positioning: Home

Brand: Philips
Category: Monitor
Model: 246E7QDSW/00
Part number: 246E7QDSW/00
EAN / UPC: 4058154018354, 8712581731717, 8712581758547
Also known as: Philips E Line LCD monitor with Ultra Wide-Color 246E7QDSW/00

Specifications

121 specifications in 14 groups

Display

Specification	Value
Display diagonal	59.9 cm (23.6")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Full HD
Panel type	PLS
LED backlight	Yes
Backlight type	W-LED
Display brightness (typical)	250 cd/m²
Response time	5 ms
Screen shape	Flat
Supported graphics resolutions	1920 x 1080 (HD 1080)
Supported video modes	1080p
Aspect ratio	16:9
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	20000000:1
Dynamic contrast ratio marketing name	Mega Contrast
Maximum refresh rate	75 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Pixel pitch	0.272 x 0.272 mm
Pixel density	123 ppi
Horizontal scan range	30 - 83 kHz
Vertical scan range	56 - 76 Hz
Viewable size, horizontal	52.1 cm
Viewable size, vertical	29.3 cm
Digital horizontal frequency	30 - 83 kHz
Digital vertical frequency	56 - 76 Hz
Sync-on-green (SOG)	Yes
Display diagonal (metric)	59.9 cm
DDC/CI	Yes
Colour gamut standard	sRGB, NTSC
Colour gamut	101.4%
sRGB coverage (typical)	117%
NTSC coverage (typical)	101.4%
3D	No
Separate H/V sync	Yes
Display sRGB	Yes
Display panel size	23.6 inch / 59.9 cm

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Component video sync	Separate Sync, Sync-on-green (SOG)
Flicker-free technology	Yes
Low Blue Light technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Home
Product colour	White
Feet colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	No
VGA (D-Sub) ports quantity	1
DVI port	No
HDMI	Yes
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	1
DisplayPort version	1.2
Audio input	No
Audio output	Yes
Headphone out	No
Mobile High-Definition Link (MHL)	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	No
Tilt adjustment	Yes
Tilt angle range	-5 - 20°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian
Number of OSD languages	21
Plug and Play	Yes
LED indicators	Operation, Stand-by

Power

Specification	Value
Power consumption (typical)	14.47 W
Power consumption (standby)	0.5 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	External
Annual energy consumption	50 kWh

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	539 mm
Depth (with stand)	179 mm
Height (with stand)	419 mm
Weight (with stand)	3.18 kg
Width (without stand)	539 mm
Depth (without stand)	45 mm
Height (without stand)	324 mm
Weight (without stand)	2.61 kg

Packaging data

Specification	Value
Package width	581 mm
Package depth	102 mm
Package height	490 mm
Package weight	5.13 kg
Package type	Box

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, HDMI
Manual	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Other features

Specification	Value
Compatible operating systems	Mac OS X; Windows 8.1 / 8 / 7
On/off switch	Yes
TV tuner integrated	No
Exterior finish type	Gloss
Compliance certificates	RoHS
Energy efficiency class (legacy scale)	B
Heavy metals free	Hg (mercury), Pb (lead)
Monitor sync input signal	Separate Sync; Sync on Green
Signal input	VGA (Analog ); DVI-D (digital, HDCP); MHL-HDMI (digital, HDCP)
Mean time between failures (MTBF)	50000 h
Certification	CE Mark, FCC Class B, CU-EAC, TCO Certified, TUV/ISO9241-307, VCCI, C-tick, WEEE, CECP
Picture enhancement	SmartImage Lite
Regulatory Approvals	CE Mark; FCC Class B; CU-EAC; TCO Certified; TUV/ISO9241-307; VCCI; C-tick; WEEE; CECP
User controls	Power On/Off; Menu; Volume (HDMI Audio out); Input; SmartImage lite
Supplied AC adapter type	AC

Recycling data

Specification	Value
Overall recyclability rate	100%
Packaging recyclability rate	100%
