246E7QDSB/11 computer monitor

59.9 cm (23.6") 1920 x 1080 pixels Full HD LED Black

Model 246E7QDSB/11EAN 609585248786

90 specifications Checked today

Display59.9 cm (23.6")
Resolution1920 x 1080 pixels
ColourBlack
NVIDIA G-SYNCNo
VESA mountingYes
Power consumption (typical)14.47 W

See all specifications

Overview

Display: 59.9 cm (23.6")
Resolution: 1920 x 1080 pixels
Colour: Black
NVIDIA G-SYNC: No
VESA mounting: Yes
Power consumption (typical): 14.47 W

Brand: Philips
Category: Monitor
Model: 246E7QDSB/11
Part number: 246E7QDSB/11
EAN / UPC: 609585248786
Also known as: Philips 246E7QDSB/11 computer monitor 59.9 cm (23.6") 1920 x 1080 pixels Full HD LED Black

Specifications

90 specifications in 12 groups

Display

Specification	Value
Display diagonal	59.9 cm (23.6")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LED
Touchscreen	No
HD type	Full HD
Panel type	PLS
LED backlight	Yes
Backlight type	W-LED
Display brightness (typical)	250 cd/m²
Response time	5 ms
Screen shape	Flat
Supported graphics resolutions	1920 x 1080 (HD 1080)
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	20000000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Pixel pitch	0.272 x 0.272 mm
Horizontal scan range	30 - 83 kHz
Vertical scan range	56 - 76 Hz
Viewable size, horizontal	52.1 cm
Viewable size, vertical	29.3 cm
Sync-on-green (SOG)	Yes
Display diagonal (metric)	59.9 cm
DDC/CI	Yes
Colour gamut standard	sRGB, NTSC
Colour gamut	101.4%
NTSC coverage (typical)	101.4%
3D	No
Display sRGB	Yes
Display panel size	23.6 inch / 59.9 cm

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Flicker-free technology	Yes

Design

Specification	Value
Product colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	No
VGA (D-Sub) ports quantity	1
DVI port	Yes
DVI-D ports quantity	1
HDMI ports quantity	1
HDCP	Yes
Mobile High-Definition Link (MHL)	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Tilt adjustment	Yes
Tilt angle range	-5 - 20°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian

Power

Specification	Value
Power consumption (typical)	14.47 W
Power consumption (standby)	0.5 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	External

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	539 mm
Depth (with stand)	179 mm
Height (with stand)	419 mm
Weight (with stand)	3.18 kg
Width (without stand)	539 mm
Depth (without stand)	45 mm
Height (without stand)	324 mm
Weight (without stand)	2.61 kg

Packaging data

Specification	Value
Package width	595 mm
Package depth	115 mm
Package height	497 mm
Package weight	5.13 kg

Sustainability

Specification	Value
Sustainability certificates	EPEAT Silver, ENERGY STAR

Other features

Specification	Value
Compatible operating systems	Mac OS X; Windows 8.1 / 8 / 7
On/off switch	Yes
TV tuner integrated	No
Exterior finish type	Gloss
LowBlue mode	Yes
Monitor sync input signal	Separate Sync; Sync on Green
Signal input	VGA (Analog ); DVI-D (digital, HDCP); MHL-HDMI (digital, HDCP)
Mean time between failures (MTBF)	50000 h
Compliance industry standards	CE mark, FCC Class B, CU-EAC, TCO Certification, TUV / ISO 9241-307, VCCI, C-Tick, WEEE, CECP
Certification	RoHS
Picture enhancement	SmartImage Lite
Regulatory Approvals	CE Mark; FCC Class B; CU-EAC; TCO Certified; TUV/ISO9241-307; VCCI; C-tick; WEEE; CECP
User controls	Power On/Off; Menu; Volume (HDMI Audio out); Input; SmartImage lite

Recycling data

Specification	Value
Packaging recyclability rate	100%
