Brilliance 190S9FB
19" SXGA LCD monitor
Model 190S9FB/93EAN 8712581430269
81 specifications Checked today
- Display48.3 cm (19")
- Resolution1280 x 1024 pixels
- ColourBlack
- Windows operating systems supportedYes
- Built-in speaker(s)No
- Power consumption (typical)36 W
Overview
- Display
- 48.3 cm (19")
- Resolution
- 1280 x 1024 pixels
- Colour
- Black
- Windows operating systems supported
- Yes
- Built-in speaker(s)
- No
- Power consumption (typical)
- 36 W
- Brand
- Philips
- Category
- Monitor
- Model
- 190S9FB/93
- Part number
- 190S9FB/93
- EAN / UPC
- 8712581430269
- Also known as
- Philips Brilliance 190S9FB 19" SXGA LCD monitor
Specifications
81 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 48.3 cm (19") |
| Display resolution | 1280 x 1024 pixels |
| Display technology | LCD |
| Touchscreen | No |
| HD type | SXGA |
| Panel type | TFT |
| Display brightness (typical) | 300 cd/m² |
| Response time | 5 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 1280 x 1024 (SXGA) |
| Contrast ratio (typical) | 800:1 |
| Contrast ratio (dynamic) | 8000:1 |
| Dynamic contrast ratio marketing name | SmartContrast |
| Viewing angle, horizontal | 176° |
| Viewing angle, vertical | 170° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.294 x 0.294 mm |
| Horizontal scan range | 30 - 83 kHz |
| Vertical scan range | 56 - 75 Hz |
| Sync-on-green (SOG) | Yes |
| DDC/CI | Yes |
| Colour gamut standard | sRGB |
| 3D | No |
| Separate H/V sync | Yes |
| Composite sync | Yes |
Performance
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Feet colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| HDMI ports quantity | 0 |
| HDCP | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | No |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20° |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Simplified Chinese, German, English, French, Italian, Portuguese, Russian |
| Number of OSD languages | 8 |
| Plug and Play | Yes |
| LED indicators | Operation, Stand-by |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 36 W |
| Power consumption (off) | 0.8 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Relative humidity | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 404 mm |
| Depth (with stand) | 186 mm |
| Height (with stand) | 418 mm |
| Weight (with stand) | 3.85 kg |
| Width (without stand) | 404 mm |
| Depth (without stand) | 68 mm |
| Height (without stand) | 350 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 451 mm |
| Package depth | 162 mm |
| Package height | 465 mm |
| Package weight | 5.24 kg |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| On/off switch | Yes |
| TV tuner integrated | No |
| Power consumption (economy mode) | 27 W |
| Mean time between failures (MTBF) | 50000 h |
| Certification | CE Mark, Energy Star, FCC Class B, SEMKO, TCO '03, TÜV/GS, TÜV Ergo, UL/cUL |
| Box depth (imperial) | 16.1 cm (6.36") |
| Box height (imperial) | 46.5 cm (18.3") |
| Set depth (inch) | 6.81 cm (2.68") |
| Set depth (with stand) (inch) | 18.6 cm (7.32") |
| Set height (inch) | 35 cm (13.8") |
| Set height (with stand) (inch) | 41.9 cm (16.5") |
| Weight (with stand) (imperial) | 3.85 kg (8.49 lbs) |
