S Line 170S9/00 computer monitor

43.2 cm (17") 1280 x 1024 pixels SXGA LCD Black

Model 170S9/00EAN 8712581760892

113 specifications Checked today

Display43.2 cm (17")
Resolution1280 x 1024 pixels
ColourBlack
NVIDIA G-SYNCNo
Market positioningOffice
VESA mountingYes

See all specifications

Overview

Display: 43.2 cm (17")
Resolution: 1280 x 1024 pixels
Colour: Black
NVIDIA G-SYNC: No
Market positioning: Office
VESA mounting: Yes

Brand: Philips
Category: Monitor
Model: 170S9/00
Part number: 170S9/00
EAN / UPC: 8712581760892
Also known as: Philips S Line 170S9/00 computer monitor 43.2 cm (17") 1280 x 1024 pixels SXGA LCD Black

Specifications

113 specifications in 14 groups

Display

Specification	Value
Display diagonal	43.2 cm (17")
Display resolution	1280 x 1024 pixels
Native aspect ratio	5:4
Display technology	LCD
Touchscreen	No
HD type	SXGA
Panel type	TFT
LED backlight	Yes
Backlight type	W-LED
Display brightness (typical)	250 cd/m²
Response time	1 ms
Anti-glare screen	Yes
Screen shape	Flat
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	50000000:1
Dynamic contrast ratio marketing name	SmartContrast
Maximum refresh rate	60 Hz
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.7 million colours
Pixel pitch	0.264 x 0.264 mm
Pixel density	96 ppi
Horizontal scan range	30 - 83 kHz
Vertical scan range	50 - 76 Hz
Viewable size, horizontal	33.8 cm
Viewable size, vertical	27 cm
Sync-on-green (SOG)	Yes
Display diagonal (metric)	43.2 cm
DDC/CI	Yes
Haze rate	25%
Surface hardness	3H
Colour gamut standard	sRGB, NTSC
Colour gamut	87%
sRGB coverage (typical)	103%
NTSC coverage (typical)	87%
Display sRGB	Yes
Display panel size	17 inch / 43.2 cm

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Component video sync	Separate Sync, Sync-on-green (SOG)
Flicker-free technology	Yes
Low Blue Light technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Office
Product colour	Black
Front bezel colour	Black
Feet colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	No
VGA (D-Sub) ports quantity	1
DVI port	Yes
DVI-D ports quantity	1
HDCP	Yes
HDCP version	1.4

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Wall mountable	Yes
Cable management	Yes
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	No
Tilt adjustment	Yes
Tilt angle range	-5 - 25°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian
Number of OSD languages	21
Plug and Play	Yes
LED indicators	Operation, Stand-by

Power

Specification	Value
Power consumption (typical)	8.87 W
Power consumption (standby)	0.3 W
Power consumption (off)	0.3 W
Power consumption (PowerSave)	8.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	Internal

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	367 mm
Depth (with stand)	196 mm
Height (with stand)	393 mm
Weight (with stand)	2.34 kg
Width (without stand)	367 mm
Depth (without stand)	46 mm
Height (without stand)	309 mm
Weight (without stand)	2 kg

Packaging data

Specification	Value
Package width	450 mm
Package depth	127 mm
Package height	453 mm
Package weight	3.55 kg

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, VGA
Manual	Yes
Bundled software	SmartControl

Sustainability

Specification	Value
Sustainability certificates	China Energy Label (CEL), ENERGY STAR
Doesn't contain	PVC/BFR
Sustainability compliance	Yes

Other features

Specification	Value
Compatible operating systems	Mac OS X; Windows 10 / 8.1 / 8 / 7
Exterior finish type	Textured
Compliance certificates	CCC, CE, Federal Communications Commission (FCC), RoHS, WEEE
EasyRead mode	Yes
LowBlue mode	Yes
Monitor sync input signal	Separate Sync; Sync on Green
No flickering	Yes
Signal input	DVI-D (digital, HDCP); VGA (Analog )
Mean time between failures (MTBF)	70000 h
Picture enhancement	SmartImage
Regulatory Approvals	CE Mark; FCC Class B; SEMKO; CCC; CECP; CEL
User controls	SmartImage; Input; Brightness; Menu; Power On/Off

Recycling data

Specification	Value
Packaging recyclability rate	100%
Product post-consumer recycled plastic	25%
