170S8FS 17" SXGA LCD monitor
Model 170S8FS/62EAN 8712581356491
46 specifications Checked yesterday
- Display43.2 cm (17")
- Resolution1280 x 1024 pixels
- Built-in speaker(s)No
- VGA (D-Sub) ports quantity1
- Panel mounting interface100 x 100 mm
- Power consumption (typical)33 W
Overview
- Display
- 43.2 cm (17")
- Resolution
- 1280 x 1024 pixels
- Built-in speaker(s)
- No
- VGA (D-Sub) ports quantity
- 1
- Panel mounting interface
- 100 x 100 mm
- Power consumption (typical)
- 33 W
- Brand
- Philips
- Category
- Monitor
- Model
- 170S8FS/62
- Part number
- 170S8FS/62
- EAN / UPC
- 8712581356491
- Also known as
- Philips 170S8FS 17" SXGA LCD monitor
Specifications
46 specifications in 10 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1280 x 1024 pixels |
| Touchscreen | No |
| Display brightness (typical) | 300 cd/m² |
| Response time | 5 ms |
| Contrast ratio (typical) | 800:1 |
| Contrast ratio (dynamic) | 3000:1 |
| Viewing angle, horizontal | 176° |
| Viewing angle, vertical | 170° |
| Pixel pitch | 0.264 x 0.264 mm |
| Horizontal scan range | 30 - 83 kHz |
| Vertical scan range | 56 - 75 Hz |
| Pixel frequency | 140 MHz |
| Video input impedance | 75 Ω |
| Video input signal levels | 0.7 Vpp |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
Ergonomics
| Specification | Value |
|---|---|
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Tilt angle range | -5 - 20° |
| Plug and Play | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 33 W |
| Power consumption (off) | 1 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Relative humidity | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 378.5 mm |
| Width (without stand) | 378.5 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 452.1 mm |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| TV tuner integrated | No |
| Effective viewing area | 337.9 x 270.3 mm |
| Power requirements | 100-240VAC, 50/60Hz |
| Signal input | VGA |
| Mean time between failures (MTBF) | 50000 h |
| Certification | CE Mark, EMC, Energy Star, FCC-B, UL, CSA, SEMKO, TÜV/GS, TÜV Ergo, TCO '03 |
| Box depth (imperial) | 16 cm (6.3") |
| Box height (imperial) | 39.1 cm (15.4") |
| Set depth (inch) | 5.84 cm (2.3") |
| Set depth (with stand) (inch) | 21.1 cm (8.3") |
| Set height (inch) | 32.8 cm (12.9") |
| Set height (with stand) (inch) | 38.6 cm (15.2") |
| Weight (with stand) (imperial) | 4.58 kg (10.1 lbs) |
| Supplied AC adapter type | AC |
