162B9TN/00 computer monitor

39.6 cm (15.6") 1366 x 768 pixels HD LCD Touchscreen Tabletop Black

Model 162B9TN/00EAN 8712581761851

139 specifications Checked today

Display39.6 cm (15.6")
Resolution1366 x 768 pixels
Energy classE
ColourBlack
NVIDIA G-SYNCNo
Built-in speaker(s)Yes

See all specifications

Overview

Display: 39.6 cm (15.6")
Resolution: 1366 x 768 pixels
Energy class: E
Colour: Black
NVIDIA G-SYNC: No
Built-in speaker(s): Yes

Brand: Philips
Category: Monitor
Model: 162B9TN/00
Part number: 162B9TN/00
EAN / UPC: 8712581761851
Also known as: Philips 162B9TN/00 computer monitor 39.6 cm (15.6") 1366 x 768 pixels HD LCD Touchscreen Tabletop Black

Specifications

139 specifications in 15 groups

Display

Specification	Value
Display diagonal	39.6 cm (15.6")
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	Yes
HD type	HD
Panel type	TN
LED backlight	Yes
Backlight type	W-LED
Touchscreen type	Tabletop
Touchscreen technology	Projected capacitive system
Touch technology	Multi-touch
Number of simultaneous touchpoints	10
Display brightness (typical)	220 cd/m²
Display brightness	220 cd/m²
Response time	4 ms
Display surface	Gloss
Screen shape	Flat
Supported graphics resolutions	1366 x 768
Supported video modes	768p
Aspect ratio	16:9
Contrast ratio (typical)	500:1
Contrast ratio (dynamic)	20000000:1
Dynamic contrast ratio marketing name	SmartContrast
Maximum refresh rate	60 Hz
Viewing angle, horizontal	90°
Viewing angle, vertical	60°
Display number of colours	262000 colours
Pixel pitch	0.252 x 0.252 mm
Pixel density	100 ppi
Horizontal scan range	30 - 60 kHz
Vertical scan range	50 - 75 Hz
Viewable size, horizontal	34.4 cm
Viewable size, vertical	19.4 cm
Digital horizontal frequency	30 - 60 kHz
Digital vertical frequency	50 - 75 Hz
Display diagonal (metric)	39.6 cm
DDC/CI	Yes
Surface hardness	7H
Colour gamut standard	sRGB, NTSC
Colour gamut	86%
sRGB coverage (typical)	100%
NTSC coverage (typical)	86%
Display sRGB	Yes
Display panel size	15.6 inch/39.6 cm

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Component video sync	Separate Sync, Sync-on-green (SOG)
Low Blue Light technology	Yes
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Mac operating systems supported	Yes
Linux operating systems supported	Yes
Palm rejection	Yes

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	4 W
Built-in camera	No
Built-in microphone	No

Design

Specification	Value
Product colour	Black
Front bezel colour	Black
Feet colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB Type-A downstream ports quantity	2
USB Touch port	Yes
VGA (D-Sub) ports quantity	1
DVI port	Yes
DVI-D ports quantity	1
HDMI	Yes
HDMI ports quantity	1.4
HDMI version	1.4
DisplayPorts quantity	1.2
DisplayPort version	1.2
Audio input	1
Headphone out	Yes
Headphone outputs	1
PC Audio in	Yes
HDCP	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Wall mountable	Yes
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	No
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian
Number of OSD languages	21
Palm rejection area	25 x 25 mm
Plug and Play	Yes
LED indicators	Operation, Stand-by

Power

Specification	Value
Energy efficiency class (SDR)	E
Power consumption (typical)	7.1 W
Power consumption (standby)	0.3 W
Power consumption (off)	0.3 W
Power consumption (PowerSave)	5.6 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	External
Energy efficiency scale	A+++ to D

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m

Weight & dimensions

Specification	Value
Width (without stand)	378 mm
Depth (without stand)	42 mm
Height (without stand)	241 mm
Weight (without stand)	2.01 kg

Packaging data

Specification	Value
Package width	445 mm
Package depth	159 mm
Package height	388 mm
Package weight	3.44 kg
Package type	Box

Packaging content

Specification	Value
Cables included	HDMI, USB Type-A to USB Type-B, AC
Stylus included	Yes
Manual	Yes
Bundled software	SmartControl

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR
Doesn't contain	Mercury, PVC/BFR

Other features

Specification	Value
International Protection (IP) code	IP65
Compatible operating systems	Windows 10 / 8.1 / 8 / 7
Exterior finish type	Textured
Compliance certificates	RoHS, WEEE
Display viewable area (HxV)	344.2 x 193.5 mm
EasyRead mode	Yes
Energy efficiency class (legacy scale)	E
Heavy metals free	Hg (mercury)
LowBlue mode	Yes
Mobile operating systems supported	Android 7.1, Android 7.0, Android 6.0, Android 5.0, Android 4.4
Monitor sync input signal	Separate Sync; Sync on Green
Signal input	VGA (Analogue); DVI-D (digital, HDCP); DisplayPort 1.2; HDMI 1.4
Mean time between failures (MTBF)	70000 h
Certification	CB, CE Mark, FCC Class B, SEMKO, UKRAINIAN, ICES-003, TUV/GS, TUV Ergo, CU-EAC, EAEU RoHS
Picture enhancement	SmartImage
Regulatory Approvals	CB; CE Mark; FCC Class B; SEMKO; UKRAINIAN; ICES-003; TUV/GS; TUV Ergo; CU-EAC; EAEU RoHS
Touch method	Stylus, Finger, Glove*
User controls	SmartImage; Input; Brightness; Menu; Power On/Off
Supplied AC adapter type	1366 x 768 @ 60 Hz, Y

Recycling data

Specification	Value
Packaging recyclability rate	100%

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
