NEC Reference 242

NEC Reference 242

Model Reference 242Part no. 60003543EAN 4053162585294

77 specifications Checked 3 days ago
  • Display61 cm (24")
  • Resolution1920 x 1200 pixels
  • Energy classC
  • ColourBlack
  • Built-in speaker(s)No
  • Market positioningBusiness
See all specifications

Overview

Display
61 cm (24")
Resolution
1920 x 1200 pixels
Energy class
C
Colour
Black
Built-in speaker(s)
No
Market positioning
Business
Brand
NEC
Category
Monitor
Model
Reference 242
Part number
60003543
EAN / UPC
4053162585294, 5028695110397, 5053959394848
Also known as
NEC SpectraView Reference 242 computer monitor 61 cm (24") 1920 x 1200 pixels LED Black

Specifications

77 specifications in 14 groups

Display

Display diagonal61 cm (24")
Display resolution1920 x 1200 pixels
Native aspect ratio16:10
Display technologyLED
TouchscreenNo
Panel typeAH-IPS
Backlight typeRGB LED
Display brightness (typical)340 cd/m²
Response time8 ms
Screen shapeFlat
Supported graphics resolutions720 x 400, 720 x 480, 720 x 576, 832 x 624, 1152 x 870, 1200 x 1920, 1280 x 960, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Supported video modes1080p, 480p, 576p, 720p
Aspect ratio16:10
Contrast ratio (typical)1000:1
Viewing angle, horizontal178°
Viewing angle, vertical178°
Display number of colours1.073 billion colours
Pixel pitch0.27 x 0.27 mm
Horizontal scan range31.5 - 93.8 kHz
Vertical scan range50 - 85 Hz
DDC/CIYes
Colour gamut standardsRGB
3DNo

Multimedia

Built-in speaker(s)No
Built-in cameraNo

Design

Market positioningBusiness
Product colourBlack

Ports & interfaces

Built-in USB hubNo
USB Type-A downstream ports quantity0
VGA (D-Sub) ports quantity1
DVI portYes
DVI-D ports quantity1
HDMI ports quantity1
DisplayPorts quantity1
AC (power) inYes

Network

Wi-FiNo
BluetoothNo
Ethernet LANNo

Ergonomics

VESA mountingYes
Panel mounting interface100 x 100 mm
Cable lock slotYes
Cable lock slot typeKensington
Height adjustmentYes
Adjustable height (max)15 cm
PivotYes
Pivot angle0 - 90°
SwivellingYes
Swivel angle range-45 - 45°
Tilt adjustmentYes
Tilt angle range-5 - 30°
Picture-in-PictureYes
On Screen Display (OSD)Yes
Plug and PlayYes
LED indicatorsPower

Power

Power consumption (typical)37 W
Power consumption (max)56 W
Power consumption (PowerSave)2 W
AC input voltage100 - 240 V
Annual energy consumption54 kWh

Operational conditions

Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80%

Weight & dimensions

Width (with stand)556.8 mm
Depth (with stand)227.6 mm
Height (with stand)378 mm
Weight (with stand)10.6 kg
Width (without stand)556.8 mm

Packaging data

User Guide on CD-ROMYes

Packaging content

ManualYes

Sustainability

Sustainability certificatesENERGY STAR

Other features

On/off switchYes
TV tuner integratedNo
ECO modeYes
Energy efficiency class (legacy scale)C
Power consumption (economy mode)28 W
CertificationC-tick; CCC; CE; EAC; FCC Class B; ISO 9241-307 (pixel failure class I); MPR II/ MPR III; PCBC/B-mark; PSB; RoHS; TÜV Ergonomics; TÜV GS; UL/C-UL or CSA
Supplied AC adapter typeLED

Thin Client

Thin client installedNo
