LCD3215 + Wallmount
Model LCD3215 + WallmountPart no. 60002472/KIT
43 specifications Checked today
- Display81.3 cm (32")
- Resolution1360 x 768 pixels
- ColourBlack
- Built-in speaker(s)Yes
- VGA (D-Sub) ports quantity2
- Panel mounting interface400 x 200 mm
Overview
- Display
- 81.3 cm (32")
- Resolution
- 1360 x 768 pixels
- Colour
- Black
- Built-in speaker(s)
- Yes
- VGA (D-Sub) ports quantity
- 2
- Panel mounting interface
- 400 x 200 mm
- Brand
- NEC
- Category
- Monitor
- Model
- LCD3215 + Wallmount
- Part number
- 60002472/KIT
- Also known as
- NEC LCD3215 + Wallmount computer monitor 81.3 cm (32") 1360 x 768 pixels Black
Specifications
43 specifications in 9 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 81.3 cm (32") |
| Display resolution | 1360 x 768 pixels |
| Native aspect ratio | 16:9 |
| Touchscreen | No |
| Display brightness (typical) | 500 cd/m² |
| Response time | 9 ms |
| Supported graphics resolutions | 720 x 400, 832 x 624 |
| Supported video modes | 480i, 480p, 576i, 576p |
| Aspect ratio | 16:9 |
| Contrast ratio (typical) | 800:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.511 x 0.511 mm |
| Horizontal scan range | 31.5 - 91.1 kHz |
| Vertical scan range | 50 - 85 Hz |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| VGA (D-Sub) ports quantity | 2 |
| DVI-D ports quantity | 1 |
| Audio input | Yes |
| Audio output | Yes |
| Headphone connectivity | 3.5 mm |
| Composite video in | 1 |
| Composite video out | 1 |
| Component video (YPbPr/YCbCr) in | 1 |
| RS-232 ports | 1 |
| S-Video inputs quantity | 1 |
Ergonomics
| Specification | Value |
|---|---|
| Panel mounting interface | 400 x 200 mm |
| Plug and Play | Yes |
| LED indicators | Stand-by |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 115 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (without stand) | 789 mm |
| Depth (without stand) | 133 mm |
| Height (without stand) | 476.3 mm |
| Weight (without stand) | 13.1 kg |
Other features
| Specification | Value |
|---|---|
| TV tuner integrated | No |
| Display viewable area (HxV) | 697.7 x 392.3 mm |
| Power requirements | 100 - 120 V, 220-240 V, 1.4 A/0.6 A |
| Compliance industry standards | VESA DDC2B |
