MultiSync EA245WMi-2 computer monitor

61 cm (24") 1920 x 1200 pixels WUXGA LED Black

Model EA245WMi-2Part no. 60004486EAN 4058154322437

90 specifications Checked today

Display61 cm (24")
Resolution1920 x 1200 pixels
ProcessorAMD Ontario
Energy classE
ColourBlack
NVIDIA G-SYNCNo

See all specifications

Overview

Display: 61 cm (24")
Resolution: 1920 x 1200 pixels
Processor: AMD Ontario
Energy class: E
Colour: Black
NVIDIA G-SYNC: No

Brand: NEC
Category: Monitor
Model: EA245WMi-2
Part numbers: 60004486, 60004488
EAN / UPC: 4058154322437, 5028695115330, 5028695115347
Also known as: NEC MultiSync EA245WMi-2 computer monitor 61 cm (24") 1920 x 1200 pixels WUXGA LED Black

Specifications

90 specifications in 14 groups

Display

Specification	Value
Display diagonal	61 cm (24")
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Display technology	LED
Touchscreen	No
HD type	WUXGA
Panel type	IPS
Backlight type	W-LED
Display brightness (typical)	300 cd/m²
Response time	6 ms
Screen shape	Flat
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	5000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.78 million colours
Pixel pitch	0.27 x 0.27 mm
Viewable size, horizontal	51.8 cm
Viewable size, vertical	32.4 cm
Digital horizontal frequency	31.5 - 95 kHz
Digital vertical frequency	56 - 75 Hz
Sync-on-green (SOG)	Yes
3D	No
Separate H/V sync	Yes
Composite sync	Yes

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	2 W
Built-in camera	No

Design

Specification	Value
Product colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	1
USB Type-A downstream ports quantity	3
VGA (D-Sub) ports quantity	1
DVI port	Yes
DVI-D ports quantity	1
HDMI ports quantity	1
DisplayPorts quantity	2
Headphone outputs	1
HDCP	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	Yes
Adjustable height (max)	15 cm
Pivot	Yes
Pivot angle	-90 - 90°
Swivelling	Yes
Swivel angle range	-170 - 170°
Tilt adjustment	Yes
Tilt angle range	-5 - 35°
On Screen Display (OSD)	Yes
Plug and Play	Yes

Power

Specification	Value
Energy efficiency class (SDR)	E
Energy consumption (SDR) per 1000 hours	16 kWh
Power consumption (typical)	18 W
Power consumption (max)	28 W
Power consumption (PowerSave)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 85%
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m

Weight & dimensions

Specification	Value
Width (with stand)	531.5 mm
Depth (with stand)	250 mm
Height (with stand)	515.4 mm
Weight (with stand)	6.7 kg
Weight (without stand)	4.2 kg

Packaging content

Specification	Value
Cables included	AC, DisplayPort, USB
Quick start guide	Yes

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Other features

Specification	Value
On/off switch	Yes
Rotating	Yes
TV tuner integrated	No
Light sensor	Yes
Power consumption (economy mode)	22 W
Certification	TCO 7.0
Supplied AC adapter type	AC

Thin Client

Specification	Value
Processor family	AMD Ontario

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
