MultiSync EA193Mi computer monitor
48.3 cm (19") 1280 x 1024 pixels SXGA LED Black
Model EA193MiPart no. 60003585EAN 5028695110151
84 specifications Checked today
- Display48.3 cm (19")
- Resolution1280 x 1024 pixels
- Energy classD
- ColourBlack
- Built-in speaker(s)Yes
- Built-in USB hubNo
Overview
- Display
- 48.3 cm (19")
- Resolution
- 1280 x 1024 pixels
- Energy class
- D
- Colour
- Black
- Built-in speaker(s)
- Yes
- Built-in USB hub
- No
- Brand
- NEC
- Category
- Monitor
- Model
- EA193Mi
- Part numbers
- 60003585, 60003586
- EAN / UPC
- 5028695110151, 4053162536005, 5028695110168, 5028695112667 +5 more
- Also known as
- NEC MultiSync EA193Mi computer monitor 48.3 cm (19") 1280 x 1024 pixels SXGA LED Black
Specifications
84 specifications in 14 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 48.3 cm (19") |
| Display resolution | 1280 x 1024 pixels |
| Native aspect ratio | 5:4 |
| Display technology | LED |
| Touchscreen | No |
| HD type | SXGA |
| Panel type | IPS |
| Backlight type | W-LED |
| Display brightness (typical) | 250 cd/m² |
| Response time | 6 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 720 x 400, 832 x 624, 1152 x 870, 1280 x 768, 1280 x 960, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Aspect ratio | 5:4 |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.293 x 0.293 mm |
| Digital horizontal frequency | 31.5 - 81.1 kHz |
| Digital vertical frequency | 56 - 75 Hz |
| DDC/CI | Yes |
| Colour gamut standard | sRGB |
| 3D | No |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 2 W |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| USB Type-A downstream ports quantity | 0 |
| VGA (D-Sub) ports quantity | 1 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| HDMI ports quantity | 0 |
| DisplayPorts quantity | 1 |
| HDCP | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet LAN | No |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 11 cm |
| Pivot | Yes |
| Pivot angle | 0 - 90° |
| Swivelling | Yes |
| Swivel angle range | -45 - 45° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20° |
| On Screen Display (OSD) | Yes |
| Plug and Play | Yes |
| LED indicators | Power |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | D |
| Energy consumption (SDR) per 1000 hours | 10 kWh |
| Power consumption (typical) | 14 W |
| Power consumption (max) | 18 W |
| Power consumption (PowerSave) | 0.35 W |
| AC input voltage | 100 - 240 V |
| Energy efficiency scale | A to G |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 408 mm |
| Depth (with stand) | 213.9 mm |
| Height (with stand) | 386.4 mm |
| Weight (with stand) | 5.9 kg |
| Width (without stand) | 408 mm |
| Depth (without stand) | 65 mm |
| Height (without stand) | 338 mm |
| Weight (without stand) | 3.9 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC, DVI, VGA |
| Manual | Yes |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | EPEAT Gold, ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| On/off switch | Yes |
| TV tuner integrated | No |
| ECO mode | Yes |
| Light sensor | Yes |
| Power consumption (economy mode) | 10 W |
| Certification | CE; Energy Star 6.0; ErP; FCC Class B; ISO 9241-307 (pixel failure class I); MPR II/ MPR III; PCT/Gost; RoHS; TCO 6.0; TÜV Ergonomics; TÜV GS; UL/C-UL or CSA |
| Supplied AC adapter type | AC |
Thin Client
| Specification | Value |
|---|---|
| Thin client installed | No |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85285210 |
