NEC MultiSync E224F computer monitor

MultiSync E224F computer monitor

55.9 cm (22") 1920 x 1080 pixels Full HD LCD Black

Model E224FPart no. 60005828EAN 5028695125421

66 specifications Checked today

Display55.9 cm (22")
Resolution1920 x 1080 pixels
Energy classD
ColourBlack
Flicker-free technologyYes
Built-in USB hubNo

See all specifications

Overview

Display: 55.9 cm (22")
Resolution: 1920 x 1080 pixels
Energy class: D
Colour: Black
Flicker-free technology: Yes
Built-in USB hub: No

Brand: NEC
Category: Monitor
Model: E224F
Part numbers: 60005828, 60005842
EAN / UPC: 5028695125421, 5028695125490
Also known as: NEC MultiSync E224F computer monitor 55.9 cm (22") 1920 x 1080 pixels Full HD LCD Black

Specifications

66 specifications in 11 groups

Display

Specification	Value
Display diagonal	55.9 cm (22")
Display resolution	1920 x 1080 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Full HD
Panel type	TFT
Backlight type	W-LED
Display brightness (typical)	250 cd/m²
Response time	6 ms
Screen shape	Flat
Contrast ratio (typical)	3000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Pixel pitch	0.249 x 0.249 mm
Vertical scan range	50 - 75 Hz
Display diagonal (metric)	55 cm

Performance

Specification	Value
Flicker-free technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	2 W
Built-in camera	No

Design

Specification	Value
Product colour	Black
Front bezel colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	No
VGA (D-Sub) ports quantity	1
HDMI	Yes
HDMI ports quantity	1
DisplayPorts quantity	1
Headphone out	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable management	Yes
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	Yes
Adjustable height (max)	12 cm
Pivot	Yes
Pivot angle	-90 - 90°
Swivelling	Yes
Swivel angle range	-170 - 170°
Tilt adjustment	Yes
Tilt angle range	-5 - 25°
On Screen Display (OSD)	Yes

Power

Specification	Value
Energy efficiency class (SDR)	D
Energy consumption (SDR) per 1000 hours	12 kWh
Power consumption (typical)	14 W
Power consumption (PowerSave)	0.22 W
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 85%

Weight & dimensions

Specification	Value
Width (with stand)	493.2 mm
Depth (with stand)	233.2 mm
Height (with stand)	483.4 mm
Weight (with stand)	5.2 kg
Weight (without stand)	3.1 kg
Bezel width (side)	2.5 mm
Bezel width (top)	2.5 mm
Bezel width (bottom)	1.68 cm

Packaging content

Specification	Value
Stand included	Yes
Cables included	AC, DisplayPort

Other features

Specification	Value
Compliance certificates	RoHS, cTUVus, WEEE
