Optix MAG301RF
Model Optix MAG301RFPart no. OPTIX MAG301RFEAN 824142235782
87 specifications Checked today
- Display74.9 cm (29.5")
- Resolution2560 x 1080 pixels
- Energy classG
- ColourBlack
- NVIDIA G-SYNCYes
- Built-in speaker(s)No
Overview
- Display
- 74.9 cm (29.5")
- Resolution
- 2560 x 1080 pixels
- Energy class
- G
- Colour
- Black
- NVIDIA G-SYNC
- Yes
- Built-in speaker(s)
- No
- Brand
- MSI
- Category
- Monitor
- Model
- Optix MAG301RF
- Part number
- OPTIX MAG301RF
- EAN / UPC
- 824142235782, 824142235805, 4719072780661, 4719072889784
- Also known as
- MSI Optix MAG301RF computer monitor 74.9 cm (29.5") 2560 x 1080 pixels 2K Ultra HD LED Black
Specifications
87 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 74.9 cm (29.5") |
| Display resolution | 2560 x 1080 pixels |
| Native aspect ratio | 21:9 |
| Display technology | LED |
| Touchscreen | No |
| HD type | 2K Ultra HD |
| Panel type | IPS |
| Display brightness (typical) | 300 cd/m² |
| Response time | 1 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 100000000:1 |
| Maximum refresh rate | 200 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.2697 x 0.2697 mm |
| Viewable size, horizontal | 69 cm |
| Viewable size, vertical | 29.1 cm |
| Digital horizontal frequency | 60 - 250.7 kHz |
| Digital vertical frequency | 48 - 200 Hz |
| Display diagonal (metric) | 75 cm |
| Colour gamut standard | DCI-P3 |
| Colour gamut | 85% |
| sRGB coverage (typical) | 105% |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | Yes |
| AMD FreeSync | No |
| NVIDIA G-SYNC type | G-SYNC Compatible |
| AMD FreeSync refresh rate range | 48 - 165 Hz |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Gaming |
| Product colour | Black |
| Frameless design | Yes |
| Feet colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB hub version | 2.0 |
| USB upstream port type | USB Type-B |
| Number of USB Type-B upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 2 |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2a |
| Headphone out | Yes |
| Headphone outputs | 1 |
| DC-in jack | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 13 cm |
| Swivelling | Yes |
| Swivel angle range | -45 - 45° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20° |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 29 kWh |
| Energy consumption (HDR) per 1000 hours | 37 kWh |
| Power consumption (typical) | 32 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 1.6 A |
| Energy efficiency scale | A to G |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 5000 m |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 709.4 mm |
| Depth (with stand) | 234 mm |
| Height (with stand) | 399.2 mm |
| Weight (with stand) | 7.2 kg |
| Width (without stand) | 709.4 mm |
| Depth (without stand) | 60 mm |
| Height (without stand) | 326 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 960 mm |
| Package depth | 180 mm |
| Package height | 510 mm |
| Package weight | 9.9 kg |
Packaging content
| Specification | Value |
|---|---|
| Stand included | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85285210 |
