Optix MAG245R2
Model Optix MAG245R2Part no. OPTIX MAG245R2EAN 4719072837334
87 specifications Checked today
- Display60.5 cm (23.8")
- Resolution1920 x 1080 pixels
- Energy classE
- ColourBlack
- NVIDIA G-SYNCYes
- Built-in speaker(s)No
Overview
- Display
- 60.5 cm (23.8")
- Resolution
- 1920 x 1080 pixels
- Energy class
- E
- Colour
- Black
- NVIDIA G-SYNC
- Yes
- Built-in speaker(s)
- No
- Brand
- MSI
- Category
- Monitor
- Model
- Optix MAG245R2
- Part number
- OPTIX MAG245R2
- EAN / UPC
- 4719072837334
- Also known as
- MSI Optix MAG245R2 computer monitor 60.5 cm (23.8") 1920 x 1080 pixels Full HD LCD Black
Specifications
87 specifications in 10 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LCD |
| Touchscreen | No |
| HD type | Full HD |
| Panel type | IPS |
| Display brightness (typical) | 250 cd/m² |
| Response time | 1 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Aspect ratio | 16:9 |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 100000000:1 |
| Maximum refresh rate | 170 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.2745 x 0.2745 mm |
| Horizontal scan range | 30 - 100 kHz |
| Vertical scan range | 48 - 170 Hz |
| Viewable size, horizontal | 52.7 cm |
| Viewable size, vertical | 29.6 cm |
| Display diagonal (metric) | 60 cm |
| Colour gamut standard | DCI-P3 |
| Colour gamut | 81.62% |
| sRGB coverage (typical) | 102.57% |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | Yes |
| AMD FreeSync | Yes |
| AMD FreeSync type | FreeSync Premium |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Gaming |
| Product colour | Black |
| Frameless design | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB hub version | 2.0 |
| USB upstream port type | USB Type-B |
| Number of upstream ports | 1 |
| Number of USB Type-B upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 2 |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 1.4b |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2a |
| Audio output | Yes |
| Headphone out | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 13 cm |
| Pivot | Yes |
| Pivot angle | -90 - 90° |
| Swivelling | Yes |
| Swivel angle range | -45 - 45° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20° |
| On Screen Display (OSD) | Yes |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 18.3 kWh |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 2.25 A |
| AC adapter output voltage | 20 V |
| Power supply type | External |
| Energy efficiency scale | A to G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 540.3 mm |
| Depth (with stand) | 233.7 mm |
| Height (with stand) | 385.8 mm |
| Weight (with stand) | 5.7 kg |
| Width (without stand) | 540.3 mm |
| Depth (without stand) | 57.1 mm |
| Height (without stand) | 328.2 mm |
| Weight (without stand) | 2.8 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 815 mm |
| Package depth | 165 mm |
| Package height | 50 mm |
| Package weight | 7.8 kg |
| Package type | Box |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85285210 |
