MAG 342CQRF E20

Model MAG 342CQRF E20EAN 4711377392426

84 specifications Checked today

Display86.4 cm (34")
Resolution3440 x 1440 pixels
Energy classF
ColourBlack
VESA Adaptive Sync supportYes
Built-in speaker(s)No

See all specifications

Overview

Display: 86.4 cm (34")
Resolution: 3440 x 1440 pixels
Energy class: F
Colour: Black
VESA Adaptive Sync support: Yes
Built-in speaker(s): No

Brand: MSI
Category: Monitor
Model: MAG 342CQRF E20
Part number: MAG 342CQRF E20
EAN / UPC: 4711377392426
Also known as: MSI MAG 342CQRF E20 computer monitor 86.4 cm (34") 3440 x 1440 pixels UltraWide Quad HD LCD Black

Specifications

84 specifications in 11 groups

Display

Specification	Value
Display diagonal	86.4 cm (34")
Display resolution	3440 x 1440 pixels
Native aspect ratio	21:9
Display technology	LCD
Touchscreen	No
HD type	UltraWide Quad HD
Panel type	VA
Display brightness (typical)	300 cd/m²
Response time	0.5 ms
Response time measurement type	GTG (Gray to Gray)
Response time (MPRT)	1 ms
Display surface	Matt
Screen shape	Curved
Screen curvature rating	1500R
Contrast ratio (typical)	3500:1
Contrast ratio (dynamic)	100000000:1
Maximum refresh rate	200 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colours
Pixel pitch	0.23175 x 0.23175 mm
Horizontal scan range	71.81 - 285.31 kHz
Vertical scan range	48 - 200 Hz
Viewable size, horizontal	79.7 cm
Viewable size, vertical	33.4 cm
Display diagonal (metric)	86.36 cm
Colour gamut standard	DCI-P3
Colour gamut	90%
sRGB coverage (typical)	119%
DCI-P3 coverage	90%

Performance

Specification	Value
VESA Adaptive Sync support	Yes
Flicker-free technology	Yes
Low Blue Light technology	Yes

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Gaming
Product colour	Black
Frameless design	Yes

Ports & interfaces

Specification	Value
Built-in USB hub	No
DVI port	No
HDMI	Yes
HDMI ports quantity	2
HDMI version	2.0b
DisplayPorts quantity	1
DisplayPort version	1.4a
Audio input	No
Headphone out	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	75 x 75 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	Yes
Adjustable height (max)	9 cm
Pivot	Yes
Pivot angle	-5 - 5°
Swivelling	Yes
Swivel angle range	-30 - 30°
Tilt adjustment	Yes
Tilt angle range	-5 - 20°

Power

Specification	Value
Energy efficiency class (SDR)	F
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	31 kWh
Energy consumption (HDR) per 1000 hours	55 kWh
Power consumption (standby)	0.5 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	External
Energy efficiency scale	A to G

Weight & dimensions

Specification	Value
Width (with stand)	808.6 mm
Depth (with stand)	270 mm
Height (with stand)	424 mm
Weight (with stand)	6.95 kg
Width (without stand)	808.6 mm
Depth (without stand)	119.7 mm
Height (without stand)	363.9 mm
Weight (without stand)	5.4 kg

Packaging data

Specification	Value
Package width	929 mm
Package depth	223 mm
Package height	503 mm
Package weight	10.8 kg
Package type	Box

Other features

Specification	Value
Warranty period	3 year(s)

Technical details

Specification	Value
Native refresh rate	60 Hz
