MAG 322UP QD-OLED E16
Model MAG 322UP QD-OLED E16EAN 4711377319652
104 specifications Checked today
- Display80 cm (31.5")
- Resolution3840 x 2160 pixels
- Energy classF
- ColourBlack
- NVIDIA G-SYNCNo
- Market positioningGaming
Overview
- Display
- 80 cm (31.5")
- Resolution
- 3840 x 2160 pixels
- Energy class
- F
- Colour
- Black
- NVIDIA G-SYNC
- No
- Market positioning
- Gaming
- Brand
- MSI
- Category
- Monitor
- Model
- MAG 322UP QD-OLED E16
- Part number
- MAG 322UP QD-OLED E16
- EAN / UPC
- 4711377319652, 4711377319683
- Also known as
- MSI MAG 322UP QD-OLED E16 computer monitor 80 cm (31.5") 3840 x 2160 pixels 4K Ultra HD Black
Specifications
104 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 80 cm (31.5") |
| Display resolution | 3840 x 2160 pixels |
| Native aspect ratio | 16:9 |
| Display technology | QD-OLED |
| Touchscreen | No |
| HD type | 4K Ultra HD |
| Panel type | OLED |
| Display brightness (peak) | 450 cd/m² |
| Display brightness (typical) | 250 cd/m² |
| Response time | 0.03 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Display surface | Matt |
| Screen shape | Flat |
| Supported graphics resolutions | 3840 x 2160 |
| Supported video modes | 2160p |
| Aspect ratio | 16:9 |
| Contrast ratio (typical) | 1500000:1 |
| Maximum refresh rate | 165 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Pixel pitch | 0.1814 x 0.1814 mm |
| Horizontal scan range | 30 - 390 kHz |
| Vertical scan range | 48 - 165 Hz |
| Viewable size, horizontal | 69.9 cm |
| Viewable size, vertical | 39.5 cm |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | DisplayHDR 400 True Black |
| Colour depth | 10 bit |
| Colour gamut standard | DCI-P3 |
| Colour gamut | 99% |
| sRGB coverage (typical) | 138% |
| Adobe RGB coverage | 98% |
| Screen curvature | 150 cm |
| 3D | No |
| DCI-P3 coverage | 99% |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | No |
| AMD FreeSync | Yes |
| AMD FreeSync type | FreeSync Premium Pro |
| VESA Adaptive Sync support | Yes |
| Flicker-free technology | Yes |
| Low Blue Light technology | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Gaming |
| Product colour | Black |
| Front bezel colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 15 W |
| VGA (D-Sub) ports quantity | 0 |
| DVI port | No |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4a |
| Audio output | Yes |
| Headphone out | Yes |
| DC-in jack | Yes |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 11 cm |
| Pivot | Yes |
| Pivot angle | -10 - 10° |
| Swivelling | Yes |
| Swivel angle range | -30 - 30° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 15° |
| Plug and Play | Yes |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 32 kWh |
| Energy consumption (HDR) per 1000 hours | 35 kWh |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
| External power adapter | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 719.1 mm |
| Depth (with stand) | 241.9 mm |
| Height (with stand) | 593.9 mm |
| Weight (with stand) | 7.7 kg |
| Width (without stand) | 719.1 mm |
| Depth (without stand) | 69.3 mm |
| Height (without stand) | 418.3 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 935 mm |
| Package depth | 185 mm |
| Package height | 513 mm |
| Package weight | 12.3 kg |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Cables included | DisplayPort, Power |
| Quick start guide | Yes |
Other features
| Specification | Value |
|---|---|
| Brand specific technologies | MSI OLED Care 2.0, QD Premium Color |
| AC adapter included | Yes |
| TV tuner integrated | No |
| Warranty period | 3 year(s) |
Technical details
| Specification | Value |
|---|---|
| Native refresh rate | 60 Hz |
