LG 22EB23PY-B computer monitor
55.9 cm (22") 1680 x 1050 pixels LED White
Model 22EB23PY-BEAN 719192191198
104 specifications Checked 3 days ago
- Display55.9 cm (22")
- Resolution1680 x 1050 pixels
- ColourWhite
- Built-in speaker(s)Yes
- USB hub version2.0
- Wi-FiNo
Overview
- Display
- 55.9 cm (22")
- Resolution
- 1680 x 1050 pixels
- Colour
- White
- Built-in speaker(s)
- Yes
- USB hub version
- 2.0
- Wi-Fi
- No
- Brand
- LG
- Category
- Monitor
- Model
- 22EB23PY-B
- Part number
- 22EB23PY-B
- EAN / UPC
- 719192191198, 7191921911988, 8806084139306, 8806084139320
- Also known as
- LG 22EB23PY-B computer monitor 55.9 cm (22") 1680 x 1050 pixels LED White
Specifications
104 specifications in 13 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 55.9 cm (22") |
| Display resolution | 1680 x 1050 pixels |
| Native aspect ratio | 16:10 |
| Display technology | LED |
| Touchscreen | No |
| Panel type | TN+Film |
| Backlight type | W-LED |
| Display brightness (typical) | 250 cd/m² |
| Response time | 5 ms |
| Supported graphics resolutions | 1680 x 1050 (WSXGA+) |
| Aspect ratio | 16:10 |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 5000000:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.282 x 0.282 mm |
| Digital horizontal frequency | 30 - 83 kHz |
| Sync-on-green (SOG) | Yes |
| Colour gamut standard | sRGB |
| 3D | No |
| Pixel frequency | 135 MHz |
| Separate H/V sync | Yes |
| Composite sync | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 2 W |
| Built-in camera | No |
| Built-in microphone | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | White |
Ports & interfaces
| Specification | Value |
|---|---|
| USB hub version | 2.0 |
| USB Type-A downstream ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| DVI-D ports quantity | 1 |
| DVI-I ports quantity | 0 |
| HDMI ports quantity | 0 |
| DisplayPorts quantity | 1 |
| Mini DisplayPorts quantity | 0 |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| HDCP | Yes |
| AC (power) in | Yes |
| Composite video in | 0 |
| Composite video out | 0 |
| SCART ports quantity | 0 |
| RF ports quantity | 0 |
| Digital audio optical out | 0 |
| BNC input ports | 0 |
| Component video (YPbPr/YCbCr) in | 0 |
| Component video (YPbPr/YCbCr) out | 0 |
| Firewire (IEEE 1394) ports | 0 |
| RS-232 ports | 0 |
| RS-485 ports | 0 |
| S-Video inputs quantity | 0 |
| Thunderbolt ports quantity | 0 |
| Card reader integrated | No |
| Compatible memory cards | Not supported |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet LAN | No |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable lock slot | No |
| Height adjustment | Yes |
| Adjustable height (max) | 12 cm |
| Pivot | Yes |
| Pivot angle | 0 - 90° |
| Swivelling | Yes |
| Swivel angle range | 0 - 355° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20° |
| On Screen Display (OSD) | Yes |
| Plug and Play | Yes |
| Cable length | 1.8 m |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 21 W |
| Power consumption (standby) | 0.3 W |
| Power consumption (off) | 0.3 W |
| AC input frequency | 47/63 Hz |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 506 mm |
| Depth (with stand) | 239 mm |
| Height (with stand) | 365 mm |
| Weight (with stand) | 4.7 kg |
| Width (without stand) | 506 mm |
| Depth (without stand) | 58 mm |
| Height (without stand) | 339 mm |
| Weight (without stand) | 3.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 586 mm |
| Package depth | 196 mm |
| Package height | 407 mm |
| Package weight | 6.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | Audio (3.5mm), DVI, VGA |
| Quick start guide | Yes |
| Manual | Yes |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | EPEAT Gold, ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| On/off switch | Yes |
| Built-in subwoofer | No |
| Screen format adjustments | 4:3, 16:10 |
| TV tuner integrated | No |
| Placement supported | Horizontal/Vertical |
| Mean time between failures (MTBF) | 50000 h |
| Ethernet LAN (RJ-45) ports | 0 |
| Certification | RoHS, UL, CSA, SEMKO, NEMKO, FCC-B, VCCI-2, C-TICK, CE, TCO5.0, TÜV-GS, DIN-ISO9241-307 |
| Supplied AC adapter type | LED |
Thin Client
| Specification | Value |
|---|---|
| Thin client installed | No |
