17" Color TFT LCD 2ms
Model 17" Color TFT LCD 2msPart no. L1760TR
33 specifications Checked today
- Display43.2 cm (17")
- Resolution1280 x 1024 pixels
- ColourBlack
- DVI-D ports quantity1
- ErgonomicsISO 9241-3
- Power consumption (typical)35 W
Overview
- Display
- 43.2 cm (17")
- Resolution
- 1280 x 1024 pixels
- Colour
- Black
- DVI-D ports quantity
- 1
- Ergonomics
- ISO 9241-3
- Power consumption (typical)
- 35 W
- Brand
- LG
- Category
- Monitor
- Model
- 17" Color TFT LCD 2ms
- Part number
- L1760TR
- Also known as
- LG 17" Color TFT LCD 2ms computer monitor 43.2 cm (17") 1280 x 1024 pixels Black
Specifications
33 specifications in 8 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1280 x 1024 pixels |
| Native aspect ratio | 4:3 |
| Touchscreen | No |
| Display brightness (typical) | 300 cd/m² |
| Response time | 2 ms |
| Aspect ratio | 4:3 |
| Contrast ratio (typical) | 3000:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 170° |
| Display number of colours | 16.78 million colours |
| Pixel pitch | 0.264 |
| Digital horizontal frequency | 30 - 83 kHz |
| Digital vertical frequency | 56 - 75 Hz |
| Sync-on-green (SOG) | Yes |
| Separate H/V sync | Yes |
| Composite sync | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| DVI-D ports quantity | 1 |
| S-Video inputs quantity | 1 |
Ergonomics
| Specification | Value |
|---|---|
| Ergonomics | ISO 9241-3 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 35 W |
| Power consumption (standby) | 1 W |
| Power consumption (off) | 1 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (without stand) | 393 mm |
| Depth (without stand) | 226 mm |
| Height (without stand) | 391 mm |
| Weight (without stand) | 3.7 g |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Other features
| Specification | Value |
|---|---|
| Display viewable area (HxV) | 337.92 x 270.336 mm |
| Safety | UL cUL TUV-GS VESA |
| Ethernet LAN (RJ-45) ports | 0 |
| Certification | FCC-B CE |
