ThinkVision X24-20
Model ThinkVision X24-20Part no. 61BDGAR3UK
84 specifications Checked today
- Display60.5 cm (23.8")
- Resolution1920 x 1080 pixels
- ColourBlack
- NVIDIA G-SYNCNo
- Market positioningHome
- Power consumption (typical)20 W
Overview
- Display
- 60.5 cm (23.8")
- Resolution
- 1920 x 1080 pixels
- Colour
- Black
- NVIDIA G-SYNC
- No
- Market positioning
- Home
- Power consumption (typical)
- 20 W
- Brand
- Lenovo
- Category
- Monitor
- Model
- ThinkVision X24-20
- Part numbers
- 61BDGAR3UK, 61BDGAT3TK
- Also known as
- Lenovo ThinkVision X24-20 computer monitor 60.5 cm (23.8") 1920 x 1080 pixels Full HD LED Black
Specifications
84 specifications in 13 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Touchscreen | No |
| HD type | Full HD |
| Panel type | IPS |
| LED backlight | Yes |
| Backlight type | W-LED |
| Display brightness (typical) | 250 cd/m² |
| Response time | 6 ms |
| Response time measurement type | GTG (Gray to Gray) |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Supported graphics resolutions | 640 x 350, 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1366 x 768, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 3000000:1 |
| Maximum refresh rate | 75 Hz |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 178° |
| Response time (fast) | 4 ms |
| Pixel pitch | 0.2745 x 0.2745 mm |
| Pixel density | 92 ppi |
| Horizontal scan range | 15 - 83 kHz |
| Vertical scan range | 50 - 75 Hz |
| Viewable size, horizontal | 52.7 cm |
| Viewable size, vertical | 29.6 cm |
| Colour gamut | 72% |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Home |
| Product colour | Black |
| Colour name | Raven Black |
| Front bezel colour | Black |
| Feet colour | Black, Stainless steel |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| Headphone out | Yes |
| Headphone connectivity | 3.5 mm |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | No |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 30° |
| On Screen Display (OSD) | Yes |
| Number of OSD languages | 8 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 20 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 25 W |
| Power consumption (off) | 0.5 W |
| AC input voltage | 90 - 264 V |
| AC input frequency | 47/63 Hz |
| Power supply type | External |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 537.4 mm |
| Depth (with stand) | 220 mm |
| Height (with stand) | 326.4 mm |
| Weight (with stand) | 3.3 kg |
| Width (without stand) | 537.4 mm |
| Depth (without stand) | 33.8 mm |
| Height (without stand) | 326.4 mm |
| Weight (without stand) | 2.42 kg |
| Bezel width (side) | 1.1 mm |
| Bezel width (top) | 1.1 mm |
| Bezel width (bottom) | 2.23 cm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 115 mm |
| Package depth | 630 mm |
| Package height | 415 mm |
| Package weight | 4.9 kg |
Packaging content
| Specification | Value |
|---|---|
| Stand included | Yes |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR, EPEAT Silver, TCO |
| Doesn't contain | Arsenic, Mercury, PVC |
Other features
| Specification | Value |
|---|---|
| On/off switch | Yes |
| Certification | FCC Class B, TCO Displays 7.0, TCO Certifi ed Edge 2.0, WEEE |
