ThinkVision T32UD-40

Model ThinkVision T32UD-40Part no. 64B0GAR1U1EAN 198156726681

115 specifications Checked today

Display80 cm (31.5")
Resolution3840 x 2160 pixels
Energy classF
ColourBlack
NVIDIA G-SYNCNo
Built-in USB hubYes

See all specifications

Overview

Display: 80 cm (31.5")
Resolution: 3840 x 2160 pixels
Energy class: F
Colour: Black
NVIDIA G-SYNC: No
Built-in USB hub: Yes

Brand: Lenovo
Category: Monitor
Model: ThinkVision T32UD-40
Part numbers: 64B0GAR1U1, 64B0GAR1WL, 64B0GAT1U1, 64B0GAT1UU, 64B0GAT1WL, 64B0ZAR1U1 +34 more
EAN / UPC: 198156726681, 198156779861, 198156726520, 198156726865 +6 more
Also known as: Lenovo ThinkVision T32UD-40 Monitor

Specifications

115 specifications in 13 groups

Display

Specification	Value
Display diagonal	80 cm (31.5")
Display resolution	3840 x 2160 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	4K Ultra HD
Panel type	IPS
LED backlight	Yes
Backlight type	W-LED
Display brightness (typical)	350 cd/m²
Response time	6 ms
Response time measurement type	GTG (Gray to Gray)
Anti-glare screen	Yes
Screen shape	Flat
Contrast ratio (typical)	1500:1
Contrast ratio (dynamic)	3000000:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colours
Response time (fast)	4 ms
Pixel pitch	0.1816 x 0.1816 mm
Pixel density	140 ppi
Viewable size, horizontal	69.7 cm
Viewable size, vertical	39.2 cm
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
Colour depth	10 bit
Colour gamut standard	Rec. 709
Colour gamut	99%
sRGB coverage (typical)	99%

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No
Low Blue Light technology	Yes
Windows operating systems supported	Windows 10, Windows 11

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No
Built-in microphone	No

Design

Specification	Value
Product colour	Black
Colour name	Eclipse Black
Front bezel colour	Black
Detachable stand	Yes
Feet colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB upstream port type	USB Type-C
Number of upstream ports	1
Number of downstream ports	4
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	3
USB Type-C downstream ports quantity	1
USB Type-C DisplayPort Alternate Mode	Yes
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	100 W
VGA (D-Sub) ports quantity	0
HDMI	Yes
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	1
DisplayPort out quantity	0
DisplayPort version	1.4
Headphone out	No

Network

Specification	Value
Ethernet LAN	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Cable lock slot type	Kensington
Height adjustment	Yes
Adjustable height (max)	15.5 cm
Pivot	Yes
Pivot angle	-90 - 90°
Swivelling	Yes
Swivel angle range	-45 - 45°
Tilt adjustment	Yes
Tilt angle range	-5 - 23.5°
Plug and Play	Yes

Power

Specification	Value
Energy efficiency class (SDR)	F
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	30 kWh
Energy consumption (HDR) per 1000 hours	45 kWh
Power consumption (typical)	25.5 W
Power consumption (standby)	0.5 W
Power consumption (max)	195 W
Power consumption (off)	0.3 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power supply type	Internal
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 80%
Storage relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Width (with stand)	714.2 mm
Depth (with stand)	218 mm
Height (with stand)	594.3 mm
Weight (with stand)	9.2 kg
Width (without stand)	714.2 mm
Depth (without stand)	46.5 mm
Height (without stand)	413 mm
Weight (without stand)	6.3 kg
Bezel width (side)	2 mm
Bezel width (top)	2 mm
Bezel width (bottom)	1.14 cm

Packaging data

Specification	Value
Package width	950 mm
Package depth	139 mm
Package height	520 mm
Package weight	13.5 kg
Package type	Box

Packaging content

Specification	Value
Stand included	Yes
Cables included	DisplayPort, Power, USB Type-C to USB Type-C
Quick start guide	Yes
DisplayPort cable length	1.8 m
Power cable length	1.8 m

Other features

Specification	Value
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Certification	Energy Star Certified, TCO 10.0, TCO Edge 2.1, EPEAT Gold, EU Energy Efficiency Level (Level-F) TÜV Rheinland Eye Comfort 4 Stars, Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution)

Energy efficiency

ENERGY STAR certified

Displays · model A25315UT0 · certified Apr 28, 2025 · United States, Switzerland, Taiwan, Japan, Canada

Measurement	Value
On-mode power	25.2 W
Sleep-mode power	0.87 W
Off-mode power	0.17 W
