ThinkVision E20-1b
Model ThinkVision E20-1bPart no. 63A0KAR1BREAN 196378479248
57 specifications Checked today
- Display49.5 cm (19.5")
- Resolution1600 x 900 pixels
- ColourBlack
- NVIDIA G-SYNCNo
- VESA mountingYes
- Power consumption (typical)12 W
Overview
- Display
- 49.5 cm (19.5")
- Resolution
- 1600 x 900 pixels
- Colour
- Black
- NVIDIA G-SYNC
- No
- VESA mounting
- Yes
- Power consumption (typical)
- 12 W
- Brand
- Lenovo
- Category
- Monitor
- Model
- ThinkVision E20-1b
- Part number
- 63A0KAR1BR
- EAN / UPC
- 196378479248
- Also known as
- Lenovo ThinkVision E20-1b Monitor
Specifications
57 specifications in 11 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 49.5 cm (19.5") |
| Display resolution | 1600 x 900 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| HD type | HD+ |
| Panel type | TN |
| LED backlight | Yes |
| Backlight type | W-LED |
| Display brightness (typical) | 250 cd/m² |
| Response time | 5 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Response time (fast) | 2 ms |
| Pixel density | 94 ppi |
| Colour gamut | 72% |
| NTSC coverage (typical) | 72% |
Performance
| Specification | Value |
|---|---|
| NVIDIA G-SYNC | No |
| AMD FreeSync | No |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | No |
| Built-in camera | No |
| Built-in microphone | No |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Colour name | Raven Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | No |
| USB Type-C DisplayPort Alternate Mode | No |
| USB Power Delivery (USB PD) | No |
| VGA (D-Sub) ports quantity | 1 |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 0 |
| DisplayPort out quantity | 0 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | No |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Tilt adjustment | Yes |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 12 W |
| Power consumption (max) | 13 W |
| Power supply type | Internal |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 464.8 mm |
| Depth (with stand) | 204.8 mm |
| Height (with stand) | 352.6 mm |
| Weight (with stand) | 2.5 kg |
| Width (without stand) | 464.8 mm |
| Depth (without stand) | 48.3 mm |
| Height (without stand) | 283.5 mm |
| Weight (without stand) | 2.2 kg |
| Bezel width (side) | 1.58 cm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 341 mm |
| Package depth | 531 mm |
| Package height | 139 mm |
| Package weight | 3.7 kg |
Other features
| Specification | Value |
|---|---|
| Certification | TCO 9.0, RoHS, None |
