Legion Y27h-30
Model Legion Y27h-30Part no. 66F6UAC3UKEAN 196800454218
112 specifications Checked today
- Display68.6 cm (27")
- Resolution2560 x 1440 pixels
- Energy classF
- ColourBlack
- AMD FreeSyncYes
- Market positioningGaming
Overview
- Display
- 68.6 cm (27")
- Resolution
- 2560 x 1440 pixels
- Energy class
- F
- Colour
- Black
- AMD FreeSync
- Yes
- Market positioning
- Gaming
- Brand
- Lenovo
- Category
- Monitor
- Model
- Legion Y27h-30
- Part numbers
- 66F6UAC3UK, 66F6UAC3IT, 66F6UAC3US, 66F6UAC3EU
- EAN / UPC
- 196800454218, 196800454249, 196800454164, 196800454201
- Also known as
- Lenovo Legion Y27h-30 Monitor
Specifications
112 specifications in 12 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 68.6 cm (27") |
| Display resolution | 2560 x 1440 pixels |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Touchscreen | No |
| HD type | Quad HD |
| Panel type | IPS |
| LED backlight | Yes |
| Backlight type | W-LED |
| Display brightness (typical) | 400 cd/m² |
| Response time (MPRT) | 0.5 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 3000000:1 |
| Maximum refresh rate | 180 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Response time (fast) | 0.5 ms |
| Pixel pitch | 0.233 x 0.233 mm |
| Pixel density | 109 ppi |
| Viewable size, horizontal | 59.7 cm |
| Viewable size, vertical | 33.6 cm |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range (HDR) 400 |
| Colour depth | 10 bit |
| Colour gamut standard | DCI-P3 |
| Colour gamut | 95% |
| sRGB coverage (typical) | 99% |
Performance
| Specification | Value |
|---|---|
| AMD FreeSync | Yes |
| AMD FreeSync type | FreeSync Premium |
| VESA Adaptive Sync support | Yes |
| Low Blue Light technology | Yes |
Multimedia
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 6 W |
| Built-in camera | No |
| Built-in microphone | No |
Design
| Specification | Value |
|---|---|
| Market positioning | Gaming |
| Product colour | Black |
| Colour name | Raven Black |
| Stand adjustment | Tilt, Swivel, Pivot, Height Adjust Stand |
Ports & interfaces
| Specification | Value |
|---|---|
| Built-in USB hub | Yes |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-C |
| Number of upstream ports | 1 |
| Number of USB Type-B upstream ports quantity | 0 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 4 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| VGA (D-Sub) ports quantity | 0 |
| HDMI | Yes |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| DisplayPort out quantity | 0 |
| DisplayPort version | 1.4 |
| Mini DisplayPorts quantity | 0 |
| Audio output | Yes |
Network
| Specification | Value |
|---|---|
| Wi-Fi | No |
| Ethernet LAN | No |
Ergonomics
| Specification | Value |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Cable management | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 13.5 cm |
| Pivot | Yes |
| Pivot angle | -90 - 90° |
| Swivelling | Yes |
| Swivel angle range | -30 - 30° |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 25° |
| On Screen Display (OSD) | Yes |
Power
| Specification | Value |
|---|---|
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 26 kWh |
| Power consumption (typical) | 88 W |
| Power consumption (max) | 160 W |
| Power consumption (off) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
Weight & dimensions
| Specification | Value |
|---|---|
| Width (with stand) | 613.7 mm |
| Depth (with stand) | 258.8 mm |
| Height (with stand) | 536.5 mm |
| Weight (with stand) | 6.8 kg |
| Width (without stand) | 613.7 mm |
| Depth (without stand) | 258.8 mm |
| Height (without stand) | 536.5 mm |
| Weight (without stand) | 4.8 kg |
| Bezel width (side) | 2 mm |
| Bezel width (top) | 2 mm |
| Bezel width (bottom) | 2.06 cm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 160 mm |
| Package depth | 720 mm |
| Package height | 510 mm |
| Package weight | 9.8 kg |
Packaging content
| Specification | Value |
|---|---|
| Stand included | Yes |
| Cables included | AC, DisplayPort, USB Type-C |
| Quick start guide | Yes |
| DisplayPort cable length | 1.8 m |
| Power cable length | 1.8 m |
Other features
| Specification | Value |
|---|---|
| Compatible operating systems | Support Windows 10, Windows 11 |
| Compliance certificates | RoHS |
| Volume control | Yes |
| Certification | RoHS, Eyesafe Display, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Eye Comfort |
| Warranty period | 3 year(s) |
