ProLite E1980SD computer monitor

48.3 cm (19") 1280 x 1024 pixels SXGA LED Black

Model E1980SDPart no. E1980SD-B1EAN 4055895264248

67 specifications Checked today

Overview

Brand: iiyama
Category: Monitor
Model: E1980SD
Part numbers: E1980SD-B1, E1980SD-W1
EAN / UPC: 4055895264248, 4948570111664, 5053973590318
Also known as: iiyama ProLite E1980SD computer monitor 48.3 cm (19") 1280 x 1024 pixels SXGA LED Black

67 specifications in 13 groups

Specification	Value
Display diagonal	48.3 cm (19")
Display resolution	1280 x 1024 pixels
Native aspect ratio	5:4
Display technology	LED
Touchscreen	No
HD type	SXGA
Panel type	TN+Film
Display brightness (typical)	250 cd/m²
Response time	5 ms
Supported graphics resolutions	1280 x 1024 (SXGA)
Aspect ratio	5:4
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	12000000:1
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.78 million colours
Pixel pitch	0.294 x 0.294 mm
Horizontal scan range	24 - 80 kHz
Vertical scan range	56 - 75 Hz
Viewable size, horizontal	37.6 cm
Viewable size, vertical	30.1 cm
3D	No
Separate H/V sync	Yes

Specification	Value
Market positioning	Business
Product colour	Black

Specification	Value
USB Type-A downstream ports quantity	0
VGA (D-Sub) ports quantity	1
DVI-D ports quantity	1
HDMI	No
HDCP	Yes
Card reader integrated	No

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	No
Tilt adjustment	Yes
Tilt angle range	-4 - 21°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Simplified Chinese, German, English, Spanish, French, Italian, Japanese, Portuguese, Russian
Number of OSD languages	9

Specification	Value
Energy efficiency class (SDR)	E
Energy consumption (SDR) per 1000 hours	15 kWh
Power consumption (typical)	16 W
Power consumption (standby)	1 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
