Ernitec 0070-24108-M computer monitor

0070-24108-M computer monitor

20.3 cm (8") 800 x 600 pixels LCD Black

Model 0070-24108-MEAN 5715063196618

61 specifications Checked today

Display20.3 cm (8")
Resolution800 x 600 pixels
Energy classD
Weight1.4 kg
ColourBlack
Operating hours (hours/days)24/7

See all specifications

Overview

Display: 20.3 cm (8")
Resolution: 800 x 600 pixels
Energy class: D
Weight: 1.4 kg
Colour: Black
Operating hours (hours/days): 24/7

Brand: Ernitec
Category: Monitor
Model: 0070-24108-M
Part number: 0070-24108-M
EAN / UPC: 5715063196618
Also known as: Ernitec 0070-24108-M computer monitor 20.3 cm (8") 800 x 600 pixels LCD Black

Specifications

61 specifications in 12 groups

Display

Specification	Value
Display diagonal	20.3 cm (8")
Display resolution	800 x 600 pixels
Native aspect ratio	16:9
Display technology	LCD
LED backlight	Yes
Display brightness (typical)	250 cd/m²
Display brightness	250 cd/m²
Response time	5 ms
Aspect ratio	16:9
Contrast ratio (typical)	500:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	16.7 million colours
Pixel pitch	0.2025 x 0.2025 mm
3D	Yes

Performance

Specification	Value
Operating hours (hours/days)	24/7

Multimedia

Specification	Value
Number of speakers	2
RMS rated power	6 W

Design

Specification	Value
Market positioning	Industrial
Product colour	Black
Housing material	Metal
Front bezel colour	Black
Detachable stand	Yes

Ports & interfaces

Specification	Value
VGA (D-Sub) ports quantity	1
DVI-I ports quantity	0
HDMI ports quantity	1
HDMI version	2.0
DisplayPorts quantity	0
DC-in jack	Yes
BNC input ports	2

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	English

Power

Specification	Value
Energy efficiency class (SDR)	D
Energy efficiency class (HDR)	Not available
Power consumption (typical)	8 W
Power consumption (standby)	0.3 W
Power supply type	External

Operational conditions

Specification	Value
Operating temperature (T-T)	-30 - 85 °C

Packaging data

Specification	Value
Package dimensions (WxDxH)	430 x 125 x 260 mm
Package width	430 mm
Package depth	125 mm
Package height	260 mm
Package weight	2.5 kg

Packaging content

Specification	Value
Stand included	Yes
Power adapter included	Yes
Screws included	Yes
Quick start guide	Yes
Accessories included	Industrial PSU,Screw, Cable holder, Quick start guide

Other features

Specification	Value
Dimensions (WxDxH)	205 x 43 x 168 mm
Analog signal format system	PAL
Comb filter	3D
Depth	125 mm
Height	260 mm
Noise filter	Yes
Weight	1.4 kg
Width	430 mm
Mean time between failures (MTBF)	50000 h
Certification	EMC Class A
Picture enhancement	DNIe digital image processing

Technical details

Specification	Value
Native refresh rate	60 Hz
