RadiForce GX540

Model RadiForce GX540Part no. GX540-CL-P

70 specifications Checked today

Display54.1 cm (21.3")
Resolution2048 x 2560 pixels
ColourBlack
NVIDIA G-SYNCNo
Market positioningMedical
Built-in USB hubYes

See all specifications

Overview

Display: 54.1 cm (21.3")
Resolution: 2048 x 2560 pixels
Colour: Black
NVIDIA G-SYNC: No
Market positioning: Medical
Built-in USB hub: Yes

Brand: EIZO
Category: Monitor
Model: RadiForce GX540
Part number: GX540-CL-P
Also known as: EIZO RadiForce GX540 computer monitor 54.1 cm (21.3") 2048 x 2560 pixels LED Black

Specifications

70 specifications in 10 groups

Display

Specification	Value
Display diagonal	54.1 cm (21.3")
Display resolution	2048 x 2560 pixels
Native aspect ratio	5:4
Display technology	LED
Touchscreen	No
Panel type	IPS
Display brightness (typical)	1200 cd/m²
Response time	25 ms
Screen shape	Flat
Supported graphics resolutions	2048 x 2560
Aspect ratio	4:5
Contrast ratio (typical)	1200:1
Viewing angle, horizontal	176°
Viewing angle, vertical	176°
Display number of colours	Monochrome
Pixel pitch	0.165 x 0.165 mm
Viewable size, horizontal	33.8 cm
Viewable size, vertical	42.2 cm
Digital horizontal frequency	31 - 135 kHz
Digital vertical frequency	24 - 61 Hz
3D	No

Performance

Specification	Value
NVIDIA G-SYNC	No

Multimedia

Specification	Value
Built-in speaker(s)	No
Built-in camera	No

Design

Specification	Value
Market positioning	Medical
Product colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	Yes
USB version	2.0
USB hub version	2.0
USB upstream port type	USB Type-B
Number of upstream ports	1
USB Type-A downstream ports quantity	2
VGA (D-Sub) ports quantity	0
DVI port	Yes
DVI-D ports quantity	1
HDMI ports quantity	0
DisplayPorts quantity	1
DC-in jack	Yes

Ergonomics

Specification	Value
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Height adjustment	Yes
Adjustable height (max)	8.3 cm
Pivot	Yes
Pivot angle	-90 - 90°
Swivelling	Yes
Swivel angle range	0 - 344°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Swedish
Number of OSD languages	9
Tilt up angle range	0 - 30°

Power

Specification	Value
Power consumption (typical)	47 W
Power consumption (standby)	0.7 W
Power consumption (max)	108 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight & dimensions

Specification	Value
Width (with stand)	388 mm
Depth (with stand)	245.5 mm
Height (with stand)	595 mm
Weight (with stand)	11.5 kg
Width (without stand)	388 mm
Depth (without stand)	99 mm
Height (without stand)	496 mm
Weight (without stand)	8.8 kg

Packaging content

Specification	Value
Cables included	AC, DVI, DisplayPort, USB
Manual	Yes

Other features

Specification	Value
On/off switch	Yes
TV tuner integrated	No
Light sensor	Yes
Certification	CE , EN60601-1, UL60601-1, CSA C22.2 No. 601-1, IEC60601-1, VCCI-B, FCC-B, CAN ICES-3 (B), RCM, RoHS, WEEE, CCC, EAC
Supplied AC adapter type	LCD
