DuraVision FDS1903-A computer monitor

48.3 cm (19") 1280 x 1024 pixels SXGA LED Black

Model FDS1903-APart no. FDS1903-A-BK

71 specifications Checked today

Display48.3 cm (19")
Resolution1280 x 1024 pixels
Energy classE
ColourBlack
NVIDIA G-SYNCNo
Built-in speaker(s)Yes

See all specifications

Overview

Display: 48.3 cm (19")
Resolution: 1280 x 1024 pixels
Energy class: E
Colour: Black
NVIDIA G-SYNC: No
Built-in speaker(s): Yes

Brand: EIZO
Category: Monitor
Model: FDS1903-A
Part number: FDS1903-A-BK
Also known as: EIZO DuraVision FDS1903-A computer monitor 48.3 cm (19") 1280 x 1024 pixels SXGA LED Black

Specifications

71 specifications in 12 groups

Display

Specification	Value
Display diagonal	48.3 cm (19")
Display resolution	1280 x 1024 pixels
Native aspect ratio	5:4
Display technology	LED
Touchscreen	No
HD type	SXGA
Panel type	TN
Backlight type	LED
Display brightness (typical)	350 cd/m²
Response time	10 ms
Screen shape	Flat
Supported graphics resolutions	1280 x 1024 (SXGA)
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170°
Viewing angle, vertical	160°
Display number of colours	16.78 million colours
Pixel pitch	0.294 x 0.294 mm
Horizontal scan range	15 - 68 kHz
Vertical scan range	50 - 61 Hz
Viewable size, horizontal	37.6 cm
Viewable size, vertical	30.1 cm
3D	No

Performance

Specification	Value
NVIDIA G-SYNC	No
AMD FreeSync	No

Multimedia

Specification	Value
Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	1 W
Built-in camera	No

Design

Specification	Value
Market positioning	Business
Product colour	Black

Ports & interfaces

Specification	Value
Built-in USB hub	No
VGA (D-Sub) ports quantity	0
DVI port	No
HDMI ports quantity	1
DisplayPorts quantity	0
Audio input	No
Headphone out	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
HDCP	Yes
Composite video in	1

Ergonomics

Specification	Value
VESA mounting	Yes
Height adjustment	Yes
Adjustable height (max)	10 cm
Pivot	Yes
Pivot angle	0 - 90°
Swivelling	Yes
Swivel angle range	-35 - 35°
Tilt adjustment	Yes
Tilt angle range	0 - 30°
On Screen Display (OSD)	Yes
Number of OSD languages	9

Power

Specification	Value
Energy efficiency class (SDR)	E
Energy consumption (SDR) per 1000 hours	15 kWh
Power consumption (standby)	0.4 W
Power consumption (max)	24 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80%

Weight & dimensions

Specification	Value
Width (with stand)	405 mm
Depth (with stand)	205 mm
Height (with stand)	506.5 mm
Width (without stand)	405 mm
Height (without stand)	615 mm
Weight (without stand)	5.9 kg

Packaging content

Specification	Value
Manual	Yes

Other features

Specification	Value
Analog signal format system	NTSC, PAL, SECAM
Certification	CE, CB, cTUVus, FCC-A, CAN ICES-3 (A), VCCI-A, RCM, RoHS, WEEE

Logistics data

Specification	Value
Harmonized System (HS) code	85285210
